Panasonic Toughbook CF-AX2

Specifications

Panasonic Toughbook CF-AX2
Panasonic Toughbook CF-AX2 (Toughbook CF Series)
Processor
Intel Core i5-3427U 2 x 1.8 - 2.8 GHz, Ivy Bridge
Graphics adapter
Intel HD Graphics 4000, Core: 1150 MHz, Memory: 667 MHz, shared memory, igdumd64 9.17.10.2843/ Win8 64
Memory
4 GB
, 2x 2GB DDR3L, dual channel
Display
11.60 inch 16:9, 1366 x 768 pixel, Multitouch, J_LG_60 MS_9003, TN LED, glossy: no
Mainboard
Intel QM77 (Panther Point)
Storage
Samsung MZMPC128HBFU, 128 GB
Soundcard
Realtek ALC269 @ Intel Panther Point PCH - High Definition Audio Controller
Connections
2 USB 3.0 / 3.1 Gen1, 1 VGA, 1 HDMI, 1 Kensington Lock, Audio Connections: Line In & Line Out (two separate ports), Card Reader: SD, SDXC, Sensors: Ambient light sensor
Networking
Intel 82579LM Gigabit Network Connection (10/100/1000MBit/s), Intel Centrino Advanced-N 6205 (a/b/g/n = Wi-Fi 4/), Bluetooth 4.0, Sierra Wireless MC8305, HSPA+, max. 14.4 Mbps
Size
height x width x depth (in mm): 18 x 288 x 194 ( = 0.71 x 11.34 x 7.64 in)
Battery
48 Wh Lithium-Ion, 31 Wh battery (swappable; total: 48 Wh), 7.2V, 4.4 Ah, Battery runtime (according to manufacturer): 480 h
Operating System
Microsoft Windows 8 Pro 64 Bit
Camera
Webcam: 720p
Additional features
Keyboard: Chiclet, Keyboard Light: no, 36 Months Warranty, Windows 7 Professional Downgrade
Weight
1.13 kg ( = 39.86 oz / 2.49 pounds), Power Supply: 460 g ( = 16.23 oz / 1.01 pounds)
Price
2100 Euro



Pricecompare

Average Score: 80% - good
Average of 4 scores (from 3 reviews)
price: - %, performance: 71%, features: 68%, display: 76% mobility: 80%, workmanship: 88%, ergonomy: 78%, emissions: 85%

Reviews for the Panasonic Toughbook CF-AX2

80% Review Panasonic Toughbook CF-AX2 Convertible | Notebookcheck
The durable one. Panasonic's Toughbook CF-AX2 is built for demanding professional usage scenarios and supposedly comes with an extra level of resilience against concussions and pressure. With business-friendly features, more than decent performance and great mobility, the inner values are handled well too. Our detailed review will show whether the potential target group will be satisfied with the CF-AX2.
70% Panasonic Toughbook CF-AX2
Source: Good Gear Guide English Archive.org version
This semi-rugged 11.6in Ultrabook can conveniently be turned from a laptop into a tablet, but it has a keyboard that is way too cramped and uncomfortable to type on. As a tablet, though, it's very good and there is adequate performance under the hood for typical office tasks.
Single Review, online available, Medium, Date: 07/18/2013
Rating: Total score: 70%

Foreign Reviews

70% Panasonic Toughbook CF-AX2 : dur à cuire
Source: Erenumerique French FR→EN Archive.org version
Single Review, online available, Short, Date: 06/24/2013
Rating: Total score: 70%
100% 久违的精湛! 松下新款TOUGHBOOK深度评测
Source: PC Online.com.cn zh-CN→EN Archive.org version
Single Review, online available, Medium, Date: 06/17/2013
Rating: Total score: 100%

Comment

Intel HD Graphics 4000: Processor graphics card in the high end Ivy Bridge models. Offers a different clock speed in the different CPU models (ULV to desktop quad core) and therefore a different performance.

Non demanding games should be playable with these graphics cards.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


3427U: Fast Ivy-Bridge-based ULV-CPU in Q2 2012. Offers a core clock of 1.8 - 2.8 GHz and an HD 4000 GPU (350 - 1150 MHz). The TDP is rated at 17 W.» Further information can be found in our Comparison of Mobile Processsors.


11.60":

This is a standard display format for tablet computers or small convertibles. You see more on the screen than on a smartphone but you can't use big resolutions well. On the other hand, mobility is not a problem.

» To find out how fine a display is, see our DPI List.


Panasonic: Panasonic Corporation was founded in 1918 in Japan, making it one of the oldest electronics companies (although it started with light bulb sales). The company operates in several business areas, including electronics, home appliances, automotive technology, aerospace, energy, and environmental technology. Panasonic sells televisions, cameras, audio and video equipment, home appliances such as refrigerators and washing machines, batteries, solar panels and LED lighting worldwide. Panasonic is also a major supplier of components and systems to the automotive industry and has invested in artificial intelligence and robotics in recent years.


80%: This rating is not earth-shattering. This rating must actually be seen as average, since there are about as many devices with worse ratings as better ones. A purchase recommendation can only be seen with a lot of goodwill, unless it is about websites that generally rate strictly.


» Further information can be found in our Notebook Purchase Guide.
