Coffee Lake product roadmap shows six-core CPU using Socket 1151

Coffee Lake processors are likely to be Socket 1151, but could lack backward compatibility. (Source: VideoCardz)
Coffee Lake processors are likely to be Socket 1151, but could lack backward compatibility. (Source: VideoCardz)
Product road map slides for Intel Coffee Lake show a 95 W six-core CPU, and two new motherboard chipsets, Kaby Lake Refresh and Cannon Lake. The slides show Socket 1151, but there may be chipset limitations that stop Coffee Lake from being backward compatible.

Yesterday we detailed how ASRock had confirmed to a user on twitter than 200-series motherboards wouldn't support Coffee Lake. Today Chinese language website, PCEva, leaked product roadmap slides for Intel's new CPU and chipset, which is reported in English by VideoCardz.

We can see from the slides that the platform will have up to six cores at a TDP of 95 W, with four cores at a 65 W TDP. Dual-core options at 35 W TDP are planned for release at the end of 2017 or early 2018. Surprisingly these processors are also specified as Socket 1151, possibly confusing in regards to the comments from ASRock.

The more interesting slides are those detailing the motherboard chipset. The first motherboards will be running on a Kaby Lake Refresh chipset, labeled as Z370. This refresh has support for Coffee Lake processors, DDR4-2666 memory, improved memory overclocking, and up to 24 PCI-E lanes. In 2018 we can expect motherboards which are running Cannon Lake chipsets (labeled as 300-series) which natively bring improved audio, 802.11ac, USB 3.1 Gen2, Thunderbolt 3, and C10 + S0ix power management, when compared to Kaby Lake Refresh.

Based on the color coding of the "Desktop Chipset Roadmap" slide and the large "Coffee Lake-S Platform Chipset" square in the bottom corner, it appears to be confirming the statement made by ASRock around CPU backward compatibility with 200-series chipsets. If that is indeed the case and there are limitations imposed by the motherboard chipset, then the use of Socket 1151 is a very confusing decision from Intel.

This motherboard chipset road map is color coded with the product roadmap slide. (Source: VideoCardz)
This motherboard chipset road map is color coded with the product roadmap slide. (Source: VideoCardz)
Key features of the new chipsets. Bold shows changes compared to 200-series chipsets. (Source: VideoCardz)
Key features of the new chipsets. Bold shows changes compared to 200-series chipsets. (Source: VideoCardz)
This product road map is color coded with the product roadmap slide. (Source: VideoCardz)
This product road map is color coded with the product roadmap slide. (Source: VideoCardz)
Given the comments made recently by ASRock, there is a surprising reference to Socket 1151 on this slide. (Source: VideoCardz)
Given the comments made recently by ASRock, there is a surprising reference to Socket 1151 on this slide. (Source: VideoCardz)
