Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H

Specifications

Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H
Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H (VivoBook Pro 15 Series)
Processor
Intel Core Ultra 5 125H 14 x 3.6 - 4.5 GHz, Meteor Lake-H
Graphics adapter
Memory
16 GB
, DDR5-5600
Display
15.60 inch 16:9, 2880 x 1620 pixel 212 PPI, OLED, glossy: yes, 120 Hz
Storage
M.2 PCIe
Connections
2 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, Audio Connections: 3.5mm, Card Reader: SD
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.3
Size
height x width x depth (in mm): 19.9 x 355.7 x 235.3 ( = 0.78 x 14 x 9.26 in)
Battery
75 Wh Lithium-Ion, 4-cell
Operating System
Microsoft Windows 11 Home
Camera
Webcam: IR
Primary Camera: 5 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.8 kg ( = 63.49 oz / 3.97 pounds) ( = 0 oz / 0 pounds)



Price comparison

Reviews for the Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H

ASUS Vivobook Pro 15 OLED (N6506) Review: gran pantalla en un equipo compacto ideal para creadores
Source: Noticias 3D Spanish ES→EN
Positive: Attractive price; great built quality; good GPU; decent connectivity.
Single Review, online available, Very Long, Date: 05/01/2024

Comment

NVIDIA NVIDIA GeForce RTX 4060 Laptop GPU: High-end graphics card for laptops based on the Ada Lovelace architecture. Offers 8 GB GDDR6 (128 Bit) and is configurable with a TGP of 35 - 115W (+ Dynamic Boost).

These graphics cards are able to play the latest and most demanding games in high resolutions and full detail settings with enabled Anti-Aliasing.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Ultra 5 125H: A mid-range Meteor Lake family chip that debuted in December 2023. This 1st Gen Core Ultra laptop processor has come to replace 13th generation Core chips; it has 14 cores (4 + 8 + 2) and 18 threads at its disposal. Its Performance cores, of which there are 4, run at up to 4.5 GHz while its Efficient cores, of which there are 10 (8 main cores plus 2 extra ones found in the Low Power Island) run at up to 3.6 GHz. The 7-core Arc GPU, just out of the oven, serves as the integrated graphics adapter (this runs at up to 2.20 GHz) and there is a bevy of other brand-new technologies on offer as well such as the integrated AI Boost NPU with two Gen 3 engines for hardware AI workload acceleration. The chip's Intel-recommended Base power consumption is 28 W while its maximum Turbo power consumption is supposed to be within 115 W.» Further information can be found in our Comparison of Mobile Processsors.


15.60":

15-inch display variants are the standard and are used for more than half of all laptops.

The reason for the popularity of mid-sized displays is that this size is reasonably easy on the eyes, often allows high resolutions and thus offers rich details on the screen, yet does not consume too much power and the devices can still be reasonably compact - simply the standard compromise.

» To find out how fine a display is, see our DPI List.


Asus: ASUSTeK Computer Inc. is a major Taiwanese computer hardware manufacturer based in Taipei, founded in 1989. Under the Asus brand name, the company manufactures a wide range of products, including laptops, desktops, motherboards, graphics cards, monitors, smartphones and networking equipment, complete systems and PC components for end users.

Under the ROG (Republic of Gamers) brand name, ASUS manufactures gaming laptops known by gamers for their powerful specifications, dedicated graphics cards, high refresh rate displays and advanced cooling systems.

Beyond gaming, a wide range of notebooks are offered for different needs and budgets, from ultra-slim and lightweight ultrabooks to versatile 2-in-1 convertibles and budget-friendly options. In 2023, Asus had a 7% global market share of the PC market.

Customer satisfaction with ASUS notebooks concerns performance, the features, and the good price-performance ratio of ASUS notebooks. However, as with any brand, there are occasional reports of problems such as overheating, driver compatibility, or build quality issues.


» Further information can be found in our Notebook Purchase Guide.
