Intel Celeron J1900

Intel J1900

The Intel Celeron J1900 is a power efficient quad-core SoC for desktops and nettops. It is clocked at 2.0 - 2.42 GHz (Burst) and part of the Bay Trail-D platform. Thanks to the specially optimized 22 nanometer low-power process (P1271) with tri-gate transistors, performance and energy efficiency have been significantly improved compared to its predecessor.

Architecture

The processor cores are based on the new Silvermont architecture, which is an out-of-order design for the first time. The increased utilization of the pipeline and many other improvements (optimized branch prediction, increased buffers, enhanced decoders) have increased the performance per clock by about 50 percent. At the same time, however, the Hyper-Threading feature of the previous generation has been removed. Other major changes are the support for new instruction set extensions such as SSE 4.1 and 4.2 as well as AES-NI (depending on the model).

Performance

Thanks to 4 CPU cores and a clock speed of up to 2.42 GHz, the Celeron J1900 is significantly faster than previous Intel Atoms, e.g. the D2560. Presumably, the J1900 even outperforms the AMD Kabini APU A4-5000. For everyday tasks such as Internet or Office the performance is adequate, but not for very complex software or modern games.

Graphics

The HD Graphics (Bay Trail) is based on the Intel Gen7 architecture, which supports DirectX 11 and is also found in the Ivy Bridge series (e.g. HD Graphics 4000). With only 4 EUs (Execution Units) and a relatively low clock speed of up 688 - 854 MHz, the GPU is even slower than the HD Graphics (Ivy Bridge). Therefore, only older and less demanding games will run fluently.

Power Consumption

The entire SoC is rated at a TDP of 10 watts. Thus, the chip can be used in compact nettops.

SeriesIntel Celeron
CodenameBay Trail-D
Clock Rate2000 - 2420 MHz
Level 1 Cache224 KB
Level 2 Cache2048 KB
Number of Cores / Threads4 / 4
Max. Power Consumption (TDP = Thermal Design Power)10 Watt
Manufacturing Technology22 nm
Max. Temperature105 °C
SocketFCBGA1170
FeaturesIntel HD Graphics (Bay Trail, 688 - 854 MHz), Dual-Channel DDR3(L)-1333 Memory Controller, CPU Burst
64 Bit64 Bit support
Hardware VirtualizationVT-x
Starting Price $82 U.S.
Announcement Date11/01/2013
Product Link (external)Intel Celeron J1900
