Asus TUF Gaming F15 FX506LU-HN106

Specifications

Asus TUF Gaming F15 FX506LU-HN106
Asus TUF Gaming F15 FX506LU-HN106 (TUF Gaming F15 FX506 Series)
Processor
Intel Core i7-10870H 8 x 2.2 - 5 GHz, Comet Lake-H
Graphics adapter
Memory
16 GB
, DDR4-2933
Display
15.60 inch 16:9, 1920 x 1080 pixel 141 PPI, IPS, glossy: no, 144 Hz
Storage
1TB SSD
Connections
1 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm, USB-C
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 5.0
Size
height x width x depth (in mm): 24.9 x 360 x 256 ( = 0.98 x 14.17 x 10.08 in)
Battery
48 Wh Lithium-Polymer, 3-cell
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Keyboard: Chiclet, Keyboard Light: yes, 24 Months Warranty
Weight
2.3 kg ( = 81.13 oz / 5.07 pounds) ( = 0 oz / 0 pounds)



Price comparison

Reviews for the Asus TUF Gaming F15 FX506LU-HN106

ASUS TUF Gaming F15 FX506 - Top 5 Reasons to BUY or NOT to buy it
Source: Laptop Media English Archive.org version
Single Review, online available, Medium, Date: 06/01/2021
ASUS TUF Gaming F15 (FX506) review – a decent performer that is easy on your budget
Source: Laptop Media English Archive.org version
Okay, guys, this is a notebook that may provide a different experience, depending not only on the configuration but on the actual model, itself. Some units pack a 90Wh battery, which should provide great screen-on times, but on the other hand, it lacks the 2.5-inch SATA drive bay. Respectively, the 48Wh unit provides horrendous battery life but enables the option of further storage expansion. On the bright side, there are still two M.2 NVMe slots for SSDs, and two RAM SODIMM slots for up to 64GB of DDR4 memory in dual-channel mode.
Single Review, online available, Very Long, Date: 04/23/2021
ASUS TUF F15 (FX506) - disassembly and upgrade options
Source: Laptop Media English Archive.org version
Support, online available, Very Short, Date: 04/23/2021

Comment

NVIDIA GeForce GTX 1660 Ti Mobile: Mid range dedicated graphics card for laptops based on the desktop GTX 1660 Ti and therefore the Turing architecture without raytracing and Tensor cores. The performance of the Max-P variant should be similar to an older GTX 1070.

With these GPUs you are able to play modern and demanding games fluently at medium detail settings and HD resolution.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-10870H: A higher-end, octa-core processor of the Comet Lake product family. This i7 is designed for use in larger, beefier laptops; its Hyper-Threading-enabled CPU cores run at 2.2 GHz (base clock speed) to 5 GHz (max. Boost frequency when under single-thread load). The all-core Boost clock speed is 4.2 GHz. Core i7-10870H is manufactured on Intel's third-gen 14 nm process and features the 24 EU UHD Graphics 630 iGPU.» Further information can be found in our Comparison of Mobile Processsors.


15.60":

15-inch display variants are the standard and are used for more than half of all laptops.

The reason for the popularity of mid-sized displays is that this size is reasonably easy on the eyes, often allows high resolutions and thus offers rich details on the screen, yet does not consume too much power and the devices can still be reasonably compact - simply the standard compromise.

» To find out how fine a display is, see our DPI List.


Asus: ASUSTeK Computer Inc. is a major Taiwanese computer hardware manufacturer based in Taipei, founded in 1989. Under the Asus brand name, the company manufactures a wide range of products, including laptops, desktops, motherboards, graphics cards, monitors, smartphones and networking equipment, complete systems and PC components for end users.

Under the ROG (Republic of Gamers) brand name, ASUS manufactures gaming laptops known by gamers for their powerful specifications, dedicated graphics cards, high refresh rate displays and advanced cooling systems.

Beyond gaming, a wide range of notebooks are offered for different needs and budgets, from ultra-slim and lightweight ultrabooks to versatile 2-in-1 convertibles and budget-friendly options. In 2023, Asus had a 7% global market share of the PC market.

Customer satisfaction with ASUS notebooks concerns performance, the features, and the good price-performance ratio of ASUS notebooks. However, as with any brand, there are occasional reports of problems such as overheating, driver compatibility, or build quality issues.


» Further information can be found in our Notebook Purchase Guide.
