Update review Asus N56VM Notebook with GT 630M

Cheaper. After the review of the N56VZ with the powerful GeForce GT 650M, we will now have a look at the cheaper model with a GeForce GT 630M.

In addition to our in-depth review of the Asus N56VZ with the GeForce GT 650M,  we want to briefly take a look at the cheaper model with a GeForce GT 630M. Otherwise, the rest of the specifications (including the CPU and HDD) are identical, but for a total of about 50 Euro (~60 USD) less.

Our test sample is a slightly modified pre-production unit of the N56VM series which Intel has provided for the purposes of benchmarking Ivy Bridge. Contrary to the series, it features the faster Core i7-3720QM and the HDMI-out is connected to the integrated Intel HD Graphics 4000 (according to Intel). Furthermore, the pre-installed Nvidia driver was a little older and even preferred the HD 4000 when launching games.

The following article will only briefly cover the performance of the GT 630M and the matte FullHD display, as our test sample features a different display than the N56VZ series sample.

Display

The matte 16:9 FullHD display in our test sample is based on a LG Philips LP156WF1. Much to our surprise it was about 100cd/m² brighter than the Samsung 156HT01-201 in our N56VM production model. The same black value of 0.58 cd/m² remains, however, so the contrast has increased to 700:1. Therefore, the test sample is more appropriate for outdoor use and convinces with decent screen legibility.

328
cd/m²
369
cd/m²
359
cd/m²
346
cd/m²
404
cd/m²
354
cd/m²
348
cd/m²
403
cd/m²
343
cd/m²
Distribution of brightness
tested with Gossen Mavo-Monitor
Maximum: 404 cd/m² (Nits) Average: 361.6 cd/m²
Brightness Distribution: 81 %
Center on Battery: 404 cd/m²
Contrast: 685:1 (Black: 0.59 cd/m²)

Performance

The GeForce cards of the 600M series allow the manufacturer to adjust the clock rates when under load depending on the effectiveness of the cooling system. Although the GeForce GT 630M with 96 Shadern and DDR3 graphics memory is still based on the old Fermi chip of the GeForce GT 540M, the N56VM significantly increases the clock rate under load and reaches levels close to that of the old GT 550M. While Nvidia's system information only displays a meager 475/950 MHz (core/memory), GPU-z lists a core speed of 660 -  897 MHz depending on the version.

The 3DMark results range between the faster GT 550M and the slowest GT 555M.  Of course, the powerful Core i7-3720QM has an impact here.

3DMark 11 - 1280x720 Performance GPU (sort by value)
Asus N56VM (GT 630M)
1149 Points
Asus N56VZ (GT 650M)
2147 Points
Gigabyte P2532N (GT 550M)
966 Points
Asus N55SF-S1124V (GT 555M)
1251 Points
3DMark Vantage - 1280x1024 P GPU no PhysX (sort by value)
Asus N56VM (GT 630M)
4268 Points
Asus N56VZ (GT 650M)
7446 Points
Gigabyte P2532N (GT 550M)
3834 Points
Asus N55SF-S1124V (GT 555M)
5316 Points

Legend


Asus N56VM Intel Core i7-3720QM, NVIDIA GeForce GT 630M, Seagate Momentus 7200.5 ST9750420AS

Asus N56VM Intel Core i7-3720QM, NVIDIA GeForce GT 630M, Seagate Momentus 7200.5 ST9750420AS

Asus N56VZ-S4044V Intel Core i7-3610QM, NVIDIA GeForce GT 650M, Seagate Momentus SpinPoint M8 ST1000LM024

Gigabyte P2532N Intel Core i7-2630QM, NVIDIA GeForce GT 550M, WDC Scorpio Black WD7500BPKT-75PKA4T0

Asus N55SF-S1124V Intel Core i7-2630QM, NVIDIA GeForce GT 555M, Seagate Momentus 7200.5 ST9750420AS

System Performance

Thanks to its faster CPU and hard drive configuration, our test sample can clearly outperform the N56VZ production model in PCMark 7 by about 33 percent. However the lead shrinks a little bit as the GT 630M is is weaker card than the GT 650M.

5.9
Windows 7 Experience Index
Processor
Calculations per second
7.6
Memory (RAM)
Memory operations per second
7.7
Graphics
Desktop performance for Windows Aero
6.5
Gaming graphics
3D business and gaming graphics
6.5
Primary hard disk
Disk data transfer rate
5.9
PCMark 7 Score
3341 points
PCMark 10 Score
2533 points
Help

Storage Devices

The built-in Seagate ST9750420AS is a conventional HDD with a 750 GB capacity. The drive transfer average of 90 MB/s places it as a mid-range 7200 rpm hard drive. The fastest HDDs currently achieve slightly more than 100 MB/s. However, compared to the Seagate Momentus SpinPoint M8 ST1000LM024 in the N56VZ sample, the Seagate here is significantly faster.

Seagate Momentus 7200.5 ST9750420AS
Transfer Rate Minimum: 49 MB/s
Transfer Rate Maximum: 112.5 MB/s
Transfer Rate Average: 90.1 MB/s
Access Time: 15.3 ms
Burst Rate: 95.2 MB/s

Gaming Performance

In demanding games like Risen 2 or Max Payne 3, the GT 630M cannot achieve smooth frame rates beyond medium details. Older games or less demanding ones like Diablo 3 can be played at high details. Overall, only a handful of games can be played in the native 1080p display resolution.

low med. high ultra
Sims 3 (2009) 68 35
Resident Evil 5 (2009) 31.2
Dawn of War II - Chaos Rising (2010) 118 64.4 47.4 21.42
The Witcher 2: Assassins of Kings (2011) 29 18
Diablo III (2012) 105 52 33 23
Dirt Showdown (2012) 91 59 35 12

296.35 Driver

low med. high ultra
Risen 2: Dark Waters (2012) 37 23 18 9
Diablo III (2012) 94 50 32 23
Max Payne 3 (2012) 37 37 12.6 9.7
Dirt Showdown
Asus N56VM
1920x1080 Ultra Preset AA:4xMS
12 (min: 0) fps ∼14%
1366x768 High Preset AA:2xMS
35 (min: 0) fps ∼38%
1366x768 Medium Preset
59 (min: 0) fps ∼58%
1024x768 Ultra Low Preset
91 (min: 0) fps ∼70%
Asus N56VZ-S4044V
1920x1080 Ultra Preset AA:4xMS
19 (min: 0) fps ∼22%
1366x768 High Preset AA:2xMS
54 (min: 0) fps ∼59%
1366x768 Medium Preset
78 (min: 0) fps ∼77%
1024x768 Ultra Low Preset
85 (min: 0) fps ∼66%

Legend


Asus N56VM Intel Core i7-3720QM, NVIDIA GeForce GT 630M, Seagate Momentus 7200.5 ST9750420AS

Asus N56VM Intel Core i7-3720QM, NVIDIA GeForce GT 630M, Seagate Momentus 7200.5 ST9750420AS

Asus N56VZ-S4044V Intel Core i7-3610QM, NVIDIA GeForce GT 650M, Seagate Momentus SpinPoint M8 ST1000LM024
Max. Load
 36 °C
97 F
37 °C
99 F
30 °C
86 F

 37 °C
99 F
38 °C
100 F
31 °C
88 F

 35 °C
95 F
36 °C
97 F
32 °C
90 F

Maximum: 38 °C = 100 F
Average: 34.7 °C = 94 F
27 °C
81 F
33 °C
91 F
35 °C
95 F
36 °C
97 F
34 °C
93 F
40 °C
104 F
30 °C
86 F
32 °C
90 F
31 °C
88 F
Maximum: 40 °C = 104 F
Average: 33.1 °C = 92 F
Room Temperature 23 °C = 73 F | Fluke 62 Mini
(±) The average temperature for the upper side under maximal load is 34.7 °C / 94 F, compared to the average of 31.2 °C / 88 F for the devices in the class Multimedia.
(+) The maximum temperature on the upper side is 38 °C / 100 F, compared to the average of 36.9 °C / 98 F, ranging from 21.1 to 71 °C for the class Multimedia.
(±) The bottom heats up to a maximum of 40 °C / 104 F, compared to the average of 39.1 °C / 102 F
(+) In idle usage, the average temperature for the upper side is 30.9 °C / 88 F, compared to the device average of 31.2 °C / 88 F.
(±) The palmrests and touchpad can get very hot to the touch with a maximum of 36 °C / 96.8 F.
(-) The average temperature of the palmrest area of similar devices was 28.8 °C / 83.8 F (-7.2 °C / -13 F).

Verdict

Despite its higher clock rate, the GeForce GT 630M cannot keep up with the faster GT 650M in the Asus N56VZ. As a result, the surcharge of 50 Euro (~60 USD) is indeed recommended for gamers. With that said, casual gamers will be content with the performance of the GT 630M.

Similar to the N56VZ, the overall impression of this particular model is positive. We especially like the bright and improved matte FullHD display. But, it is uncertain for now whether or not the buyer will end up with a Philips or Samsung display or even a display from another manufacturer.

The system noise should also be mentioned with a high note. Fan noise is low and the speakers have a high maximum volume.

We also discovered several points of critique. We would like to see two separate mouse buttons and a DisplayPort for connecting high resolution displays as HDMI is currently limited to 1920x1200 pixels. We also did not like the positioning of the interfaces and the somewhat heavy weight.

At a price of about 1000 Euro (~1230 USD) for each model, we believe that both models are priced fairly considering the performance.

Read all 3 comments / answer
static version load dynamic
Loading Comments
Comment on this article
Please share our article, every link counts!
In Review:  Asus N56VM
In Review: Asus N56VM

Specifications

Asus N56VM (N56 Series)
Processor
Intel Core i7-3720QM 4 x 2.6 - 3.6 GHz (Intel Core i7)
Graphics adapter
NVIDIA GeForce GT 630M - 2048 MB VRAM, Core: 662 MHz, Memory: 897 MHz, DDR3, 296.35
Memory
8 GB
, 2x4096 Hynix PC3-12800
Display
15.60 inch 16:9, 1920 x 1080 pixel, glossy: no
Mainboard
Intel HM76 (Panther Point)
Storage
Seagate Momentus 7200.5 ST9750420AS, 750 GB
, 7200 rpm
Soundcard
Intel Panther Point PCH - High Definition Audio Controller
Networking
Atheros AR8161/8165 PCI-E Gigabit Ethernet Controller (10/100/1000MBit/s), Intel Centrino Wireless-N 2230 (b/g/n = Wi-Fi 4/)
Optical drive
MATSHITA BD-CMB UJ141AF
Operating System
Microsoft Windows 7 Professional 64 Bit
Weight
2.7 kg ( = 95.24 oz / 5.95 pounds) ( = 0 oz / 0 pounds)



Similar Laptops

Devices from a different Manufacturer and/or with a different CPU

Review HP Envy dv6-7202eg Notebook
GeForce GT 630M, Core i7 3630QM
Review Lenovo IdeaPad Z580 Notebook
GeForce GT 630M, Core i5 3210M
Review Asus K55VM-SX064V Notebook
GeForce GT 630M, Core i7 3610QM
Review Samsung Series 5 550P5C-T02 Notebook
GeForce GT 630M, Core i5 3210M
Review Acer Aspire 5755G Notebook
GeForce GT 630M, Core i7 2670QM

Compare Prices

Pros

+matte surfaces
+4x USB 3.0
+Keyboard light
+bright, matte FullHD display with decent viewing angles
+good sound due to external subwoofer


Cons

-loose LAN port
-inconvenient location of interfaces
-poor click pad

Shortcut

What we like

The matte and bright FullHD Display.

What we would like to see

DisplayPort and separate mouse buttons.

The competition

Without doubt the GT 650M in the Asus N56VZ.
