Asus ProArt StudioBook Pro X W730G5T-H8103R

Specifications

Asus ProArt StudioBook Pro X W730G5T-H8103R
Asus ProArt StudioBook Pro X W730G5T-H8103R (ProArt StudioBook Pro 17 Series)
Processor
Intel Xeon E-2276M 6 x 2.8 - 4.7 GHz, Coffee Lake-H
Graphics adapter
NVIDIA Quadro RTX 5000 (Laptop) - 16 GB VRAM, GDDR6
Memory
64 GB
, DDR4-2666 ECC
Display
17.30 inch 16:9, 1920 x 1080 pixel 127 PPI, IPS, glossy: no, 60 Hz
Storage
1TB SSD
Connections
3 USB 3.0 / 3.1 Gen1, 2 Thunderbolt, 1 HDMI, Audio Connections: 3.5mm, Card Reader: SD, 1 Fingerprint Reader
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.0
Size
height x width x depth (in mm): 31.9 x 382 x 265 ( = 1.26 x 15.04 x 10.43 in)
Battery
95 Wh Lithium-Ion, 6-cell
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet with Numpad, Keyboard Light: yes, 24 Months Warranty
Weight
2.5 kg ( = 88.19 oz / 5.51 pounds) ( = 0 oz / 0 pounds)
Price
6000 Euro



Price comparison

Reviews for the Asus ProArt StudioBook Pro X W730G5T-H8103R

ASUS ProArt StudioBook Pro X Review
Source: The Tech Revolutionist English Archive.org version
Our only gripe on this product is that despite it being a product that is just launched in Singapore, it is still running on the older Coffee Lake processors (It is 2 generation old now). If you have to option to wait before making a new workstation, we will recommend you to do so. We can expect new NVIDIA Quadro based on the new Ampere architecture to be out next for notebook computers, which will further improve performance at a lower price point. We do expect ASUS to refresh this notebook with new components in the future too.
Single Review, online available, Very Long, Date: 09/07/2020

Comment

NVIDIA Quadro RTX 5000 (Laptop): Professional high-end laptop graphics card based on the TU104 chip with 3,072 shaders and 16 GB GDDR6 VRAM. Compared to the desktop variant, the GPU is clocked lower. There are different versions available with 110 Watt (1035 - 1545 MHz) and 150 Watt (1350 - 1770 MHz) in addition to the even lower clocked Max-Q variant.

With these GPUs you are able to play modern and demanding games fluently at medium detail settings and HD resolution.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


E-2276M: On Coffee Lake architecture based professional processor for big and heavy laptops. Integrates six processor cores clocked at 2.8 - 4.7 GHz that support HyperThreading / SMT (12 threads). Manufactured in an improved 14nm process (14nm++). Compared to the similar consumer Intel Core i7-9850H, the Xeon is clocked a bit higher (100 - 200 MHz) and offers  support for ECC main memory.» Further information can be found in our Comparison of Mobile Processsors.
