Lenovo Yoga S740-14IIL-81RS001DGE

Specifications

Lenovo Yoga S740-14IIL-81RS001DGE
Lenovo Yoga S740-14IIL-81RS001DGE (Yoga S740-14 Series)
Processor
Intel Core i5-1035G4 4 x 1.1 - 3.7 GHz, Ice Lake-U
Graphics adapter
Intel Iris Plus Graphics G4 (Ice Lake 48 EU), Core: 1050 MHz, Dual-Channel, 27.20.100.8190
Memory
8 GB
, LPDDR4X-3733, Dual-Channel, Speicher fest verlötet, keine Speicherbänke
Display
14.00 inch 16:9, 1920 x 1080 pixel 157 PPI, AU Optronics B14HAN05.A, IPS, glossy: yes, 60 Hz
Mainboard
Intel 495 (Ice Lake-U PCH-LP Premium)
Storage
Samsung SSD PM981a MZVLB512HBJQ, 512 GB
, 512GB M.2 PCIe
Connections
2 USB 3.0 / 3.1 Gen1, 1 USB 3.2 Gen 2x2 20Gbps, 1 Thunderbolt, 1 DisplayPort, Audio Connections: 3.5mm, TPM 2.0
Networking
Intel Wi-Fi 6 AX201 (a/b/g/h/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.0
Size
height x width x depth (in mm): 18.2 x 322 x 212 ( = 0.72 x 12.68 x 8.35 in)
Battery
62 Wh, 4060 mAh Lithium-Ion, Battery runtime (according to manufacturer): 14 h
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD
Primary Camera: 0.9 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, 24 Months Warranty
Weight
1.4 kg ( = 49.38 oz / 3.09 pounds) ( = 0 oz / 0 pounds)
Price
900 Euro



Pricecompare

Reviews for the Lenovo Yoga S740-14IIL-81RS001DGE

Lenovo Yoga S740 (14) review – it has great features but disappoints with performance
Source: Laptop Media English Archive.org version
With the new processors of Intel going to the market as fast as bread is sold out in a cold autumn morning, there will be literally tons of laptops flooding the market. For us, the Yoga S740 (14) was the first we were able to test, and we had some mixed feelings by it.
Single Review, online available, Very Long, Date: 11/04/2019

Foreign Reviews

Lenovo Yoga S740: merevebb derékkal
Source: Prohardver.hu HU→EN Archive.org version
Positive: Elegant design; nice display; rich set of ports; high performance; good cooling system; long battery life. Negative: No USB-C.
Single Review, online available, Very Long, Date: 03/19/2020

Comment

Intel Iris Plus Graphics G4 (Ice Lake 48 EU): Integrated graphics card in Intel Ice-Lake G4 SoCs based on the new Gen. 11 architecture with 48 of the 64 EUs (Execution Units / Shader Cluster). The clock rate depends on the processor model ranging from 300 MHz base to 1050 - 1100 MHz boost. The Ice-Lake chips are produced in the modern 10nm+ process at Intel produced.

Modern games should be playable with these graphics cards at low settings and resolutions. Casual gamers may be happy with these cards.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i5-1035G4: A low-power, Ice Lake family processor (SoC) featuring 4 cores, 8 threads, 6 MB of L3 cache and the Iris Plus G4 (48 EUs) iGPU. This Core i5 saw the light of day in H2 2019; it is designed for use in highly portable consumer laptops. The CPU cores run at 1.1 GHz to 3.7 GHz. The Sunny Cove microarchitecture that is in use here is notable for several improvements over Skylake including support for new technologies, new instruction sets and fast LPDDR4-3733 RAM. There is no PCIe 4 support here, however.» Further information can be found in our Comparison of Mobile Processsors.


14.00":

There are hardly any tablets in this display size range anymore. For subnotebooks, on the other hand, it is the standard format.

The advantage of subnotebooks is that the entire laptop can be small and therefore easily portable. The smaller display also has the advantage of requiring less power, which further improves battery life and thus mobility. The disadvantage is that reading texts is more strenuous on the eyes. High resolutions are more likely to be found in standard laptops.

» To find out how fine a display is, see our DPI List.


Lenovo: Lenovo ("Le" from English legend, novo (Latin) for new) was founded in 1984 as a Chinese computer trading company. As of 2004, the company was the largest laptop manufacturer in China and, after acquiring IBM's PC division in 2005, the fourth largest in the world. In addition to desktops and notebooks, the company manufactures monitors, projectors, servers, etc, and specializes in developing, manufacturing and marketing consumer electronics, personal computers, software, enterprise solutions and related services.

In 2016, the company ranked first in the world in computer sales. It still held it in 2023 with about 23% global market share. Important product lines are Thinkpad, Legion and Ideapad.

In 2011, it acquired a majority stake in Medion AG, a European computer hardware manufacturer. In 2014, Motorola Mobility was purchased, which gave Lenovo a boost in the smartphone market.


» Further information can be found in our Notebook Purchase Guide.
