Leaker shows alleged Nvidia RTX 3090 PCB, later rectifies it is just for an RTX 3080 card, while Micron confirms existence of flagship RTX 3090 with GDDR6X memory

Micron recently confirmed the existence of the flagship RTX 3090 model equipped with GDDR6X memory. (Image Source: ginjfo.com)
Micron recently confirmed the existence of the flagship RTX 3090 model equipped with GDDR6X memory. (Image Source: ginjfo.com)
Even though the leaker now claims the manufacturer told him the PCB is for an RTX 3080 card, we can definitely spot a few elements that seem a bit overkill for an xx80 model: 11 memory modules for at least 22 GB of VRAM, triple 8-pin power connectors plus a hidden special chip on the back of the PCB. Micron, on the other hand, confirms that the RTX 3090 is indeed real and it will integrate the new 21 Gbps GDDR6X modules with 1 TB/s bandwidth.
, , , , , ,
search relation.
, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,


Earlier today, a strange picture of a graphics card PCB that has many parts blurred out was posted on the Bilibili Chinese forums by user YuuKi_AnS. The leaker first claimed this is the back of a custom PCB for an upcoming Colorful Vulcan RTX 3090 model, but later on rectified that the manufacturer told him it is for an RTX 3080 model. It is still unclear what model will get this PCB, because there are some elements that we would not usually find on an xx80 model.

First of all, there appear to be 11 memory modules around the GPU area amounting to at least 22 GB of RAM, which seems a bit overkill for an xx80 card. The serial numbers on the memory modules have been blurred out as well, but it looks like they could be the new Micron GDDR6X models. Moreover, there is a different Nvlink connector on the upper right side, plus the upper left side features an impressive triple 8-pin power connector, suggesting that the card could be capable of 450 W TGPs

The leaker also says that he deliberately covered the GPU area with an Intel CPU in order to better hide the special external chip on the back, which was previously speculated to be a Traversal ray tracing co-processor. However, according to a recently uncovered listing coming directly from Micron, which confirms the existence of the RTX 3090 equipped with GDDR6X VRAM, it looks like the special chip may be an AI inference accelerator.

So now we have official confirmation that the RTX 3090 is real and will be equipped with the faster 21 Gbps GDDR6x modules capable of 1 TB/s transfers. Yet again, we are still unsure if the PCB leaked on the Chinese forums is indeed for the RTX 3090 model, plus we have not heard much related to this model's launch date. It may launch with the RTX 3070 and 3080 models on September 1, or maybe at a later date.

Buy MSI GeForce RTX 2080 Super 8GB Graphics Card now on Amazon

PCB Image with less blurring but more watermarking (Image Source: YuuKi_AnS)
PCB Image with less blurring but more watermarking (Image Source: YuuKi_AnS)
RTX 3090 memory specs on the far right (Source: Micron)
RTX 3090 memory specs on the far right (Source: Micron)
