PowerVR SGX543MP2 vs PowerVR SGX545

PowerVR SGX543MP2

► remove from comparison

The PowerVR SGX543MP2 (series 5XT) is an integrated graphics card for ARM based SoCs. It is e.g. used in the Apple A5 (iPhone 4s and iPad 2) and offers 8 unified shader cores that support OpenGL ES 2.0.

PowerVR SGX545

► remove from comparison PowerVR SGX545

The PowerVR SGX545 is an integrated graphics card in some of the Intel Atom Clover Trail SoCs (for example, the Atom Z2760). Technically, the SGX545 and the GMA 3650 of the Atom N28xx models are identical. The GPU would be theoretically capable of DirectX 10.1, but Intel's implementation officially supports only Direct3D 9_3.

In the case of the Atom Z2760, the SGX545 is clocked at 533 MHz. The performance is far behind AMD's Bobcat and Kabini/Temash APUs and even worse than many ARM SoCs such as Nvidia's Tegra 3. The GPU is therefore unsuitable for 3D gaming. 1080p videos, however, will play fluently.

Corresponding to the poor performance of the GPU, the power consumption is also very low. This allows the Z2760/SGX545 to be used in passively cooled tablets.

show full text
PowerVR SGX543MP2PowerVR SGX545
PowerVR SGX500 Series
SGX554MP4 compare 32
SGX543MP4 compare 16
SGX543MP3 compare 12
SGX543MP2 8
SGX545 4/2 cores @ 0.53 GHz
SGX544MP2 compare 8/4 cores @ 0.3 - 0.53 GHz
SGX544 compare 4/2 cores @ 0.38 GHz
SGX540 compare 4/2 cores @ 0.2 GHz
SGX535 compare 2/2 cores @ 0.2 GHz
SGX531 compare 2/1 cores
SGX530 compare 2/1 cores
SGX554MP4 compare 32
SGX543MP4 compare 16
SGX543MP3 compare 12
SGX543MP2 8
SGX545 4/2 cores @ 0.53 GHz
SGX544MP2 compare 8/4 cores @ 0.3 - 0.53 GHz
SGX544 compare 4/2 cores @ 0.38 GHz
SGX540 compare 4/2 cores @ 0.2 GHz
SGX535 compare 2/2 cores @ 0.2 GHz
SGX531 compare 2/1 cores
SGX530 compare 2/1 cores
ArchitecturePowerVR SGX5PowerVR SGX5
Pipelines8 - unified4 / 2 Pixel- / Vertexshader
Shared Memorynono
APIDirectX 10.1, Shader 4.1, OpenGL ES 2.0DirectX 9_3/10.1, Shader 4.1, OpenGL 3.2
technology40 nm32 nm
FeaturesOpenGL ES 2.0
Date of Announcement16.03.2009 01.01.2010
Core Speed533 MHz
CPU in SGX545GPU Base SpeedGPU Boost / Turbo
Intel Atom Z27602 x 1800 MHz, 1.7 / 3 W533 MHz? MHz

Benchmarks

3DMark - 3DMark Ice Storm Extreme Graphics
100%
1 SGX545 +
1618 Points (0%)
3DMark - 3DMark Ice Storm Graphics
100%
1 SGX545 +
min: 2914     avg: 3025     median: 3050 (0%)     max: 3112 Points
3DMark 2001SE - 3DMark 2001 - Standard
100%
1 SGX545 +
3152 Points (3%)
3DMark 03 - 3DMark 03 - Standard
100%
1 SGX545 +
min: 1507     avg: 1791     median: 1820.5 (1%)     max: 2015 Points
3DMark 05 - 3DMark 05 - Standard
100%
1 SGX545 +
min: 613     avg: 729     median: 794 (1%)     max: 802 Points
3DMark 06 3DMark 06 - Standard 1280x1024 + PowerVR SGX545
3DMark 06
100%
1 SGX545 +
min: 306     avg: 405.6     median: 411 (1%)     max: 459 Points
3DMark 06 - Standard 1280x720 + PowerVR SGX545
3DMark 06
100%
1 SGX545 +
367 Points (1%)
Cinebench R10 Cinebench R10 Shading (32bit) + PowerVR SGX545
Cinebench R10 - Cinebench R10 Shading (32bit)
100%
1 SGX545 +
min: 363     avg: 421.7     median: 428.5 (0%)     max: 443 Points
GFXBench (DX / GLBenchmark) 2.7
GFXBench T-Rex HD Offscreen C24Z16 + PowerVR SGX545
GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
100%
1 SGX545 +
2.8 fps (0%)
AnTuTu 3DRating - Antutu 3DRating Off-screen
1174 Points (41%)
AnTuTu 3DRating - Antutu 3DRating Score
5819 Points (51%)

Average Benchmarks PowerVR SGX543MP2 → 0% n=

Average Benchmarks PowerVR SGX545 → 0% n=

- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Fifa 13

Fifa 13

2012
low 1024x768
SGX545:
7.4 8.8 9.7 10 ~ 9 fps
Diablo III

Diablo III

2012
low 1024x768
SGX545:
3.2 3.3 (!) ~ 3 fps
Mass Effect 3

Mass Effect 3

2012
low 1280x720
SGX545:
1.7  fps
Anno 2070

Anno 2070

2011
low 1024x768
SGX545:
2.1 (!) 2.9 ~ 3 fps
Fifa 12

Fifa 12

2011
med. 1024x768
SGX545:
10  fps
StarCraft 2

StarCraft 2

2010
low 1024x768
SGX545:
11  fps
Risen

Risen

2009
low 800x600
SGX545:
4.4  fps
Anno 1404

Anno 1404

2009
low 1024x768
SGX545:
5.2 7.6 ~ 6 fps
Left 4 Dead

Left 4 Dead

2008
low 640x480
SGX545:
11.8 12 ~ 12 fps
Far Cry 2

Far Cry 2

2008
low 640x480
SGX545:
7.7  fps
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
SGX545:
18.9  fps
high 1024x768
SGX545:
3.8  fps
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
SGX545:
8  fps
med. 1024x768
SGX545:
1  fps
PowerVR SGX545lowmed.highultraQHD4K
Fifa 139
Diablo III3
Mass Effect 31.7
Anno 20703
Fifa 1210
StarCraft 211
Risen4.4
Anno 14046
Left 4 Dead12
Far Cry 27.68
Trackmania Nations Forever18.93.8
World in Conflict - Benchmark81
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		11


2


1











For more games that might be playable and a list of all games and graphics cards visit our Gaming List
