Lenovo ThinkPad P40 Yoga 20GQ-000EUS

Specifications

Lenovo ThinkPad P40 Yoga 20GQ-000EUS
Lenovo ThinkPad P40 Yoga 20GQ-000EUS
Graphics adapter
NVIDIA Quadro M500M - 2048 MB, Core: 1029 MHz, Memory: 1800 MHz, DDR3, 368.39, Optimus
Memory
16384 MB
, 1066.7 MHz, 11-11-11-28, Single-Channel
Display
14.1 inch 16:9, 2560 x 1440 pixel 208 PPI, 10-point capacitive, native pen support, IPS, Name: LEN40AA, ID: LP140QH1-SPE2, glossy: yes
Mainboard
Intel Skylake-U Premium PCH
Storage
Samsung SSD PM871 MZ7LN512HCHP, 512 GB
Soundcard
Intel Skylake-U/Y PCH - High Definition Audio
Connections
3 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, 1 Kensington Lock, 1 Docking Station Port, Audio Connections: 3.5 mm combo, Card Reader: 4-in-1 (MMC, SD, SDXC, SDHC), Brightness Sensor, Sensors: Accelerometer, Gyroscope, Compass
Networking
Intel Ethernet Connection I219-LM (10/100/1000/2500/5000MBit/s), Intel Dual Band Wireless-AC 8260 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5), Bluetooth 4.2
Size
height x width x depth (in mm): 19.9 x 338 x 236 ( = 0.78 x 13.31 x 9.29 in)
Battery
53 Wh, 4390 mAh Lithium-Ion
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: HD Webcam
Additional features
Keyboard: Chiclet, Keyboard Light: yes, Service brochure, ThinkPad Pen Pro, Lenovo Tools, MS Office Trial, McAfee LiveSafe Trial, 12 Months Warranty
Weight
1.753 kg ( = 61.84 oz / 3.86 pounds), Power Supply: 287 g ( = 10.12 oz / 0.63 pounds)
Price
2000 USD



Pricecompare

Average Score: 71.95% - average
Average of 4 scores (from 3 reviews)
price: - %, performance: 72%, features: 67%, display: 80% mobility: 77%, workmanship: 81%, ergonomy: 88%, emissions: 91%

Reviews for the Lenovo ThinkPad P40 Yoga 20GQ-000EUS

77.8% Lenovo ThinkPad P40 Yoga 20GQ-000EUS Workstation Review | Notebookcheck
On-the-go workstation. Versatility is the name of the game as the P40 Yoga targets light workstation users with touchscreen features and a dedicated Quadrio GPU. For a starting price of $1500 USD, however, we were expecting a bit more in terms of performance and features.
70% Lenovo ThinkPad P40 Yoga
Source: PC Mag English
The Lenovo ThinkPad P40 Yoga is a solid laptop that sits right at the price it should for its power and feature set. It offers better performance than general business laptops, convertible or otherwise, but can't compete with more expensive mobile workstations. Yoga functionality doesn't add too much to a mobile workstation, which is probably is served well just by keeping the size and weight down as Lenovo has done here, but it doesn't hurt if you think you'd make use of it as a tablet.
Single Review, online available, Very Short, Date: 10/27/2016
Rating: Total score: 70%
70% Lenovo ThinkPad P40 Yoga
Source: Mobile Tech Review English
The Lenovo ThinkPad P40 Yoga is a unique laptop, and thus it's hard to pit it against the competition--there really isn't a direct competitor. The closest would be the Microsoft Surface Book (detachable rather than yoga-style) and Lenovo's own near mirror image ThinkPad 14 with NVIDIA GeForce 940M graphics as sold by Best Buy.
Single Review, online available, Long, Date: 08/26/2016
Rating: Total score: 70%
70% Lenovo ThinkPad P40 Yoga Review: 2-in-1 Workstation
Source: Notebookreview.com English
At the end of the day the Lenovo ThinkPad P40 Yoga is a very unique hybrid PC for a very specific type of user. If you’re someone who needs the dedicated graphics performance of a mobile workstation but also needs the flexibility of a 2-in-1 that you can convert into a tablet then this is absolutely the best choice on the market.
Single Review, online available, Medium, Date: 07/27/2016
Rating: Total score: 70%

Comment

Model: The Lenovo ThinkPad P40 Yoga 20GQ-000EUS is a mobile high performance workstation laptop for business usage. It features an Intel Core i7-6600U 2.6 GHz processor, an Intel Skylake-U Premium PCH motherboard, an Nvidia Quadro M500M graphic adapter with 2 GB VRAM, 16 GB of 1600 MHz DDR3 RAM and a Samsung 512 GB Solid State Drive PM871 MZ7LN512HCHP. Its glossy 14.1” touchscreen features a resolution of 2560 x 1440 pixels, native pen support and uses the IPS technology.

The Windows 10 Professional 64-bit system measures at 19.9 x 338 x 236 mm (0.78” x 13.31” x 9.29”) and weighs at 1.753 kg (3.86 pounds). As for connectivity, it has Intel Ethernet Connection I219-LM and Intel Dual Band Wireless-AC 8260 built in for LAN, WiFi and Bluetooth connection. For input/output connections, it features three USB 3.1 ports, a HDMI port, a DisplayPort, a Kensington Lock, a docking station port, a 3.5 mm audio jack and a 4-in-1 card reader (MMC, SD, SDXC, SDHC).

NVIDIA Quadro M500M: Workstation graphics card based on the 28 nm GM108 Maxwell chip with 384 shaders and a 64-bit memory interface. Compared to the faster M600M, the M500M features only DDR3 graphics memory with a 64-bit bus and is therefore similar to the old Quadro K620M (also Maxwell GM108). Modern games should be playable with these graphics cards at low settings and resolutions. Casual gamers may be happy with these cards. » Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.
Intel Core i7: The Intel Core i7 for laptops is based on the LG1156 Core i5/i7 CPU for desktops. The base clock speed of the CPUs is relatively low, but because of a huge Turbo mode, the cores can dynamically overclock to up to 3.2 GHz (920XM). Therefore, the CPU can be as fast as high clocked dual-core CPUs (using single threaded applications) but still offer the advantage of 4 cores. Because of the large TDP of 45 W / 55 W, the CPU is only intended for large laptops.
6600U: Skylake-based ULV dual-core processor for thin notebooks and ultrabooks. Offers an integrated HD Graphics 520 GPU and is manufactured in 14 nm.» Further information can be found in our Comparison of Mobile Processsors.
14.1":

This display size represents a treshold between the small sizes of subnotebooks and ultrabooks and the standard-sizes of office- and multimedia laptops on the other hand. Laptops with that size are somewhat rare, nowadays.

» To find out how fine a display is, see our DPI List.
1.753 kg:

This weight is typical for very big tablets, subnotebooks, ultrabooks and convertibles with a 11-13 inch display-diagonal.


Lenovo: Lenovo ( "Le" as in the English word legend and "novo" (Latin) for new) was founded in 1984 as a Chinese computer trading company. From 2004, the company has been the largest laptop manufacturer in China and got the fourth largest manufacturer worldwide after the acquisition of IBM's PC division in 2005. In addition to desktops and notebooks, the company also produces monitors, projectors, servers, etc.

In 2011, Lenovo acquired the majority of Medion AG, a European computer hardware manufacturer. In 2014, Lenovo took over Motorola Mobility, which gave them a boost in the smartphone market.

From 2014 to 2016 Lenovo's market share in the global notebook market was 20-21%, ranking second behind HP. However, the distance decreased gradually. In the smartphone market, Lenovo did not belong to the Top 5 global manufacturers in 2016.


71.95%: This rating is bad. Most notebooks are better rated. This is not a recommendation for purchase.
» Further information can be found in our Notebook Purchase Guide.
