HP Pavilion 15-cc504ur


HP Pavilion 15-cc504ur
HP Pavilion 15-cc504ur (Pavilion 15-cc Series)
Intel Core i5-7200U 2 x 2.5 - 3.1 GHz, Kaby Lake
Graphics adapter
6 GB
15.60 inch 16:10, 1920 x 1200 pixel 145 PPI
1 TB HDD + 128 GB SSD
3 USB 3.0 / 3.1 Gen1, 1 HDMI, Card Reader: undefined
802.11 b/g/n (b/g/n = Wi-Fi 4), Bluetooth 4.0
height x width x depth (in mm): 20 x 378 x 252 ( = 0.79 x 14.88 x 9.92 in)
41 Wh
Operating System
Microsoft Windows 10 Home 64 Bit
1.9 kg ( = 67.02 oz / 4.19 pounds) ( = 0 oz / 0 pounds)



Reviews for the HP Pavilion 15-cc504ur

Ноутбук HP Pavilion 15 cc504ur: Обзор
Source: Product Test RU→EN
Positive: Stylish design; slim size and light weight; comfortable touchpad; nice display; decent performance. Negative: Poor connectivity; inflexible lid.
Single Review, online available, Short, Date: 04/20/2018



The HP Pavilion 15-cc504ur is a stylish 15.6-inch mid-range laptop for home and office tasks. It balances price factor and decent performance, which is enough for home and office users. Regarding the design, the HP Pavilion 15-cc504ur looks original and attractive. It is surprisingly compact and light for a model of this level. It will not become a heavy burden and can be quite easily carried around. The weight of the device amounts to 1.974 kg, and the thickness slightly exceeds 2 cm. It is thin, but the build quality is only average.  The body material is plastic, and while the bottom is quite strong, the keyboard and cover are slightly weaker. The lid can be opened up to 135 degrees, which is quite convenient. The laptop attracts attention with a matte silver cover with a glittering company logo, which bends rather sharply and moves to the rear end, slightly hugging the case. Inside, the HP Pavilion 15 cc504ur is painted in the same color and also treated without glossy surfaces. As for hardware specifications, it features an Intel Core i5-7200U processor, 6 GB of DDR4-2133 SDRAM (1 x 2 GB, 1 x 4 GB), an NVIDIA® GeForce® 940MX with 2 GB of dedicated DDR3 RAM, a 128 GB M.2 SSD and a 1 TB 5400 rpm SATA HDD. The processor has two processing cores operating at frequencies of up to 3.1 GHz with Hyper-Threading technology support. It provides good performance for office and student work, even with slight multitasking.

Working with multimedia is also possible, because the processor supports hardware acceleration of decoding video with Intel QuickSync. Thanks to the GPU, users are able to play modern and demanding games without a hitch at medium detail settings and HD resolution. The HP Pavilion 15’s screen is quite good. At 15.6 inches and with a Full HD resolution, it is large enough for work. Most importantly, the display comes with IPS-matrix, something rarely seen in this price segment. The pixel density of 141 per inch is standard for comfortable work with a display of this size. The laptop runs on a battery with 41 Wh. The manufacturer promises up to 10 hours of work. However, when watching a video on YouTube or browsing the internet, users can expect a battery life of only 4-5 hours. For connectivity, the HP Pavilion 15 cc504ur is equipped with a typical set of ports and interfaces, it has everything users need, even a new USB Type-C port. Other connectors available are two USB-3.0 ports, a headphone jack, a card reader, an HDMI connector, and a network port.

Hands-on article by Jagadisa Rajarathnam

NVIDIA GeForce 940MX: Mid-range laptop graphics card based on the Maxwell architecture. Compared to the older 940M, the MX now also supports GDDR5 graphics memory and maybe slightly faster clock speeds.

Modern games should be playable with these graphics cards at low settings and resolutions. Casual gamers may be happy with these cards.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.

i5-7200U: Kaby-Lake based SoC with two CPU cores clocked at 2.5 to 3.1 GHz, HyperThreading and manufactured with an improved 14nm process.» Further information can be found in our Comparison of Mobile Processsors.


15-16 inch is a standard display size for laptops and offers the biggest variety of products.

» To find out how fine a display is, see our DPI List.

1.9 kg:

This weight is typical for very big tablets, subnotebooks, ultrabooks and convertibles with a 11-13 inch display-diagonal.

HP: The Hewlett-Packard Company, founded 1935, commonly referred to as HP, is a technology corporation headquartered in California, United States. HP specializes in developing and manufacturing computing, storage, and networking hardware, software and services. Major product lines include personal computing devices, enterprise servers, related storage devices, as well as a diverse range of printers and other imaging products. Other product lines, including electronic test equipment and systems, medical electronic equipment, solid state components and instrumentation for chemical analysis. HP posted US $91.7 billion in annual revenue in 2006, making it the world's largest technology vendor in terms of sales. In 2007 the revenue was $104 billion, making HP the first IT company in history to report revenues exceeding $100 billion.

Up to 2015, the company was named Hewlett Packard Company. After a split, the computer range was renamed to HP Inc.


In the laptop segment, HP was the world's largest manufacturer from 2014 to 2016 with a market share of 20-21% from 2014 to 2016, but they only exceed Lenovo by a small margin as of recently. HP is not present in the smartphone sector (as of 2016).

» Further information can be found in our Notebook Purchase Guide.
