TCL 505

Specifications

TCL 505
TCL 505 (500 Series)
Processor
Mediatek Helio G36 8 x 2.2 GHz, Cortex-A53
Graphics adapter
Memory
4 GB
Display
6.75 inch 20:9, 1600 x 720 pixel 260 PPI, Capacitive, IPS, 90 Hz
Storage
64GB / 128GB
Connections
USB-C Power Delivery (PD), Audio Connections: 3.5mm, Card Reader: microSD, 1 Fingerprint Reader, NFC, Sensors: accelerometer
Networking
802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 5.1, GSM, UMTS, LTE, Dual SIM, GPS
Size
height x width x depth (in mm): 8.3 x 168.3 x 76.7 ( = 0.33 x 6.63 x 3.02 in)
Battery
5010 mAh
Operating System
Android 14
Camera
Primary Camera: 50 MPix (f/1.8) + 2MP (f/2.4)
Secondary Camera: 5 MPix f/2.2
Additional features
Keyboard: OnScreen
Weight
190 g ( = 6.7 oz / 0.42 pounds) ( = 0 oz / 0 pounds)



Price comparison

Average Score: 80% - good
Average of 1 scores (from 1 reviews)

Reviews for the TCL 505

80% TCL 505 review: o smartphone que faz tudo em modo entrada de gama
Source: 4G News Portuegese PT→EN
Single Review, online available, Long, Date: 09/07/2024
Rating: Total score: 80%

Comment

Imagination PowerVR GE8320: Integrated graphics card for mid-range ARM SoCs.

These graphics cards are not suited for Windows 3D games. Office and Internet surfing however is possible.

» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Helio G36: ARM based octa core SoC (8x small ARM Cortex-A53 cores) clocked at up to 2.2 GHz. The chip also includes a Cat.4 LTE modem and a PowerVR G38320 at 680 MHz. The SoC is produced in 12nm (FinFET) and except for the higher clock speed similar to the old Helio G25.» Further information can be found in our Comparison of Mobile Processsors.


6.75":

It is a small display format for smartphones. You shouldn't be severely defective in vision, and you won't see much detail on the screen and only have a small resolution available. For that, the device should be small and handy, easy to transport.

» To find out how fine a display is, see our DPI List.


80%: This rating is not earth-shattering. This rating must actually be seen as average, since there are about as many devices with worse ratings as better ones. A purchase recommendation can only be seen with a lot of goodwill, unless it is about websites that generally rate strictly.


» Further information can be found in our Notebook Purchase Guide.
