Qualcomm Snapdragon 6 Gen 1 vs MediaTek Dimensity 7020 vs MediaTek Dimensity 920
Qualcomm Snapdragon 6 Gen 1
► remove from comparison
The Qualcomm Snapdragon 6 Gen 1 (SM6450) mobile platform was designed for Android-based smartphones and tablets and was launched in September 2022. The SoC (system-on-a-chip) is in the entry-level class and is based on ARM's v9 architecture.
The cryo CPU of the Snapdragon 6 Gen 1 is based on four ARM Cortex-A78 performance cores with clock frequencies of up to 2.2 GHz and an efficiency cluster consisting of four Cortex-A55 cores with a clock frequency of 1.8 GHz.
An Adreno 710 is used as the integrated graphics unit. The Soc also integrates a Spectra ISP (200 MP photo), a dual-channel 16-bit LPDDR 2750 MHz memory controller, an X62 5G modem (max 2.9 GBit/s download, 1.6 Gbit/s upload), a Fastconnect 6700 Wi-Fi 6E / Bluetooth 5.2 modem and Hexagon.
The SoC is manufactured in the modern 4 nm process at Samsung.
MediaTek Dimensity 7020
► remove from comparison
The Mediatek Dimensity 7020 is a fast mid-range SoC with an integrated 5G modem. It includes two fast ARM Cortex-A78 cores at up to 2.2 GHz and six power efficient Cortex-A55 cores at up to 2 GHz (Octa-Core with Heterogeneous Multi-Processing). Furthermore, the chip integrates a IMG BXM-8-256 GPU, a Wi-Fi 5 modem, a LPDDR5 / LPDDR4X memory controller, a AI processing unit and video de- and encoding.
The 5G modem supports NR 2CC and mixed duplex (TDD/FDD) and dual SIM. The download speeds can reach up to 2.77 Gbit/s.
Compared to the Dimensity 930, the 7020 offers the same specifications and seems to be a rebrand.
The Dimensity 930 and 7020 are manufactured in the modern 6nm process and should be very power efficient.
MediaTek Dimensity 920
► remove from comparison
The Mediatek Dimensity 920 is a fast mid-range SoC with an integrated 5G modem. It includes two fast ARM Cortex-A78 cores at up to 2.5 GHz and six power efficient Cortex-A55 cores at up to 2 GHz (Octa-Core with Heterogeneous Multi-Processing). Furthermore, the chip integrates a 4 core ARM Mali-G68 MC4 GPU, a Wi-fi 6 modem, a LPDDR4x memory controller, a AI processing unit and video de- and encoding.
The 5G modem supports Sub-6 GHz and dual SIM. The download speeds can reach up to 2.7 Gbit/s.
Compared to the older Dimensity 900, the 920 offers slightly higher clock speeds for the CPU and GPU.
The Dimensity 920 is manufactured in the modern 6nm process and should be very power efficient.
| Model | Qualcomm Snapdragon 6 Gen 1 | MediaTek Dimensity 7020 | MediaTek Dimensity 920 | ||||||||
| Codename | Cortex-A78 / A55 | Cortex-A78 / A55 | Cortex-A78 / A55 | ||||||||
| Series | Qualcomm Snapdragon 6 | ||||||||||
| Series: Snapdragon 6 Cortex-A78 / A55 |
| ||||||||||
| Clock | 1800 - 2200 MHz | 2000 - 2500 MHz | 2000 - 2500 MHz | ||||||||
| Cores / Threads | 8 / 8 4 x 2.2 GHz ARM Cortex-A78 4 x 1.8 GHz ARM Cortex-A55 | 8 / 8 2 x 2.2 GHz ARM Cortex-A78 6 x 2.0 GHz ARM Cortex-A55 | 8 / 8 | ||||||||
| Technology | 4 nm | 6 nm | 6 nm | ||||||||
| Features | 12-Bit Spectra Triple ISP, 7th Gen AI Engine, Wi-Fi 6E, X62 5G Modem | 2x ARM Cortex-A78 (2.2 GHz), 6x ARM Cortex-A55 (2 GHz), PowerVR BXM-8-256, 5G 2CC-CA FDD+TDD, Dual 5G SIM, Dual VoNR, UFS 3.1, LPDDR5 | 2x ARM Cortex-A78 (2.5 GHz), 6x ARM Cortex-A55 (2 GHz), ARM Mali-G68 MC4, 5G NR Sub-6 GHz, LTE | ||||||||
| iGPU | Qualcomm Adreno 710 | IMG BXM-8-256 | ARM Mali-G68 MP4 | ||||||||
| Architecture | ARM | ARM | ARM | ||||||||
| Announced | |||||||||||
| Manufacturer | www.qualcomm.com | www.mediatek.com | www.mediatek.com |
Benchmarks
Average Benchmarks Qualcomm Snapdragon 6 Gen 1 → 100% n=15
Average Benchmarks MediaTek Dimensity 7020 → 95% n=15
Average Benchmarks MediaTek Dimensity 920 → 82% n=15
- Average benchmark values for this graphics card* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation
