Intel Core m3-7Y32 vs Intel Core i7-7560U

Intel Core m3-7Y32

► remove Intel m3-7Y32

The Intel Core m3-7Y32 is a very efficient dual-core SoC for tablets and passively cooled notebooks based on the Kaby Lake architecture and was announced early 2017. It is the more or less the successor to the in 2016 introduced Core m3-7Y30 that offers 400 MHz less Turbo Boost clock speed. Thanks to Hyper Threading, the processor can execute up to four threads simultaneously. The chips also includes the Intel HD Graphics 615 GPU, a dual-channel memory controller (DDR3L/LPDDR3) as well as VP9 and H.265 video de- and encoder. It is still produced in a 14 nm process with FinFET transistors.

Architecture

Intel basically used the familiar micro architecture from the Skylake generation, so the per-MHz performance is identical. Only the Speed-Shift technology for faster dynamic adjustments of the voltages and clocks was improved, and the matured 14 nm process now also enables much higher frequencies and better efficiency than before.

Performance

Since Intel basically removed the Core m5 and Core m7 series or included them into the higher i5 and i7 series, respectively, the m3-7Y32 is officially the last Core-m chip (together with the former m3-7Y30). Thanks to its high Turbo clock, the 7Y32 can sometimes keep up with the 15 Watt models for short peak load and single-thread scenarios, but the clocks will drop significantly under sustained workloads. The CPU is still suitable for many more demanding applications as well as multitasking. Thanks to the improved efficiency, the CPU can often even beat the Core m5 and m7 siblings from the previous Skylake generation.

Graphics

The integrated Intel HD Graphics 615 GPU has 24 Execution Units (EUs) like the old HD Graphics 515 and runs with clocks between 300 and 900 MHz in combination with this processor. The performance heavily depends on the TDP limit as well as the memory configuration; with fast LPDDR3-1866 RAM in dual-channel mode, the GPU should sometimes be able to compete with the HD Graphics 520, but can also be much slower in other scenarios. Modern games from 2016 will, if at all, only run smoothly in the lowest settings.

Contrary to Skylake, Kaby Lake now also supports hardware decoding for H.265/HEVC Main10 with a 10-bit color depth as well as Google's VP9 codec.

Power Consumption

The chip is manufactured in an improved 14 nm process with FinFET transistors, so the power efficiency was once again improved significantly. The typical TDP for the Y-series is specified at 4.5 Watts, and can be adjusted in both directions depending on the usage scenario.

Intel Core i7-7560U

► remove Intel i7-7560U

The Intel Core i7-7560U is a fast dual-core SoC for notebooks and Ultrabooks based on the Kaby Lake architecture and was announced in January 2017. The CPU has two processor cores clocked at 2.4-3.8 GHz (two cores up to 3.7 GHz). The processor can execute up to four threads simultaneously thanks to Hyper Threading. It is also equipped with an Intel Iris Plus Graphics 640 GPU with 64 MB eDRAM, a dual-channel memory controller (DDR4) as well as VP9 and H.265 video decoding as well as encoding. The chip is still manufactured in a 14nm process with FinFET transistors.

Compared to the Core i7-7500U, the 7560 does have a higher single-core Turbo of 3.8 GHz (+300 MHz) and a higher dual-core Turbo (+200 MHz). The base frequency is lower (-300 MHz), but the CPU part can also use the 64 MB eDRAM as L5 cache.

Architecture

Intel basically uses the same micro architecture compared to Skylake, so the per-MHz performance does not differ. The manufacturer only reworked the Speed Shift technology for faster dynamic adjustments of voltages and clocks, and the improved 14nm process allows much higher frequencies combined with better efficiency than before.

Performance

At 2.4-3.8 GHz, the Core i7-7560U has a slightly lower frequency (except for the single-core Turbo) compared to the Core i7-7600U, but the CPU part can also use the 64 MB eDRAM, so the performance should be similar.

Graphics

The integrated Intel Iris Plus 640 Graphics is the GT3e model of the Kaby Lake GPU (Intel Gen. 9.5). It has 48 Execution Units running at 300-1050 MHz and the performance is comparable to a GeForce 920MX thanks to fast eDRAM cache. However, there aren't any significant improvements compared to the old Iris Pro 540, so modern games can often not be played smoothly or only at the lowest or medium settings, respectively.

Contrary to Skylake, Kaby lake now also supports H.265/HEVC Main 10 with a 10-bit color depth as well as Google's VP9 codec. The dual-core Kaby Lake processors announced in January should also support HDCP 2.2.

Power Consumption

The chip is manufactured in an improved 14nm process with FinFET transistors, which improves the efficiency even further. Intel still specifies the TDP with 15 Watts, which is typical for ULV chips. Depending on the usage scenario, the TDP can vary between 7.5 (cTDP Down) and 25 Watts.

Intel Core m3-7Y32Intel Core i7-7560U
Intel Kaby LakeIntel Kaby Lake
Kaby LakeKaby Lake
: Kaby Lake Kaby Lake
Intel Core i7-7700K compare4200 - 4500 MHz4 / 88 MB
Intel Core i7-7700 compare3600 - 4200 MHz4 / 88 MB
Intel Xeon E3-1535M v6 compare3100 - 4200 MHz4 / 88 MB
Intel Core i7-7920HQ compare3100 - 4100 MHz4 / 88 MB
Intel Core i7-7700T compare2900 - 3800 MHz4 / 88 MB
Intel Core i5-7600K compare3800 - 4200 MHz4 / 48 MB
Intel Xeon E3-1505M v6 compare3000 - 4000 MHz4 / 88 MB
Intel Core i7-7820HQ compare2900 - 3900 MHz4 / 88 MB
Intel Core i7-7820HK compare2900 - 3900 MHz4 / 88 MB
Intel Core i7-7700HQ compare2800 - 3800 MHz4 / 86 MB
Intel Core i5-7500 compare3400 - 3800 MHz4 / 46 MB
Intel Core i5-7440HQ compare2800 - 3800 MHz4 / 46 MB
Intel Core i7-7567U compare3500 - 4000 MHz2 / 44 MB
Intel Core i7-7660U compare2500 - 4000 MHz2 / 44 MB
Intel Core i7-7600U compare2800 - 3900 MHz2 / 44 MB
Intel Core i5-7300HQ compare2500 - 3500 MHz4 / 46 MB
Intel Core i5-7500T compare2700 - 3300 MHz4 / 46 MB
Intel Core i5-7287U compare3300 - 3700 MHz2 / 44 MB
Intel Core i7-7560U2400 - 3800 MHz2 / 44 MB
Intel Core i5-7360U compare2300 - 3600 MHz2 / 44 MB
Intel Core i5-7267U compare3100 - 3500 MHz2 / 44 MB
Intel Core i7-7500U compare2700 - 3500 MHz2 / 44 MB
Intel Core i5-7300U compare2600 - 3500 MHz2 / 43 MB
Intel Core i5-7260U compare2200 - 3400 MHz2 / 44 MB
Intel Core i5-7200U compare2500 - 3100 MHz2 / 43 MB
Intel Core i3-7100H compare3000 MHz2 / 43 MB
Intel Core i3-7167U compare2800 MHz2 / 43 MB
Intel Core i3-7130U compare2700 MHz2 / 43 MB
Intel Core i7-7Y75 compare1300 - 3600 MHz2 / 44 MB
Intel Core i5-7Y57 compare1200 - 3300 MHz2 / 44 MB
Intel Core i5-7Y54 compare1200 - 3200 MHz2 / 44 MB
Intel Core i3-7100U compare2400 MHz2 / 43 MB
» Intel Core m3-7Y321000 - 3000 MHz2 / 44 MB
Intel Pentium Gold 4415U compare2300 MHz2 / 42 MB
Intel Core m3-7Y30 compare1000 - 2600 MHz2 / 44 MB
Intel Celeron 3965U compare2200 MHz2 / 22 MB
Intel Core i3-7020U compare2300 MHz2 / 43 MB
Intel Celeron 3867U compare1800 MHz2 / 22 MB
Intel Celeron 3865U compare1800 MHz2 / 22 MB
Intel Pentium Gold 4425Y compare1700 MHz2 / 42 MB
Intel Pentium Gold 4415Y compare1600 MHz2 / 42 MB
Intel Pentium Gold 4410Y compare1500 MHz2 / 42 MB
Intel Celeron 3965Y compare1500 MHz2 / 22 MB
Intel Core i7-7700K compare4200 - 4500 MHz4 / 88 MB
Intel Core i7-7700 compare3600 - 4200 MHz4 / 88 MB
Intel Xeon E3-1535M v6 compare3100 - 4200 MHz4 / 88 MB
Intel Core i7-7920HQ compare3100 - 4100 MHz4 / 88 MB
Intel Core i7-7700T compare2900 - 3800 MHz4 / 88 MB
Intel Core i5-7600K compare3800 - 4200 MHz4 / 48 MB
Intel Xeon E3-1505M v6 compare3000 - 4000 MHz4 / 88 MB
Intel Core i7-7820HQ compare2900 - 3900 MHz4 / 88 MB
Intel Core i7-7820HK compare2900 - 3900 MHz4 / 88 MB
Intel Core i7-7700HQ compare2800 - 3800 MHz4 / 86 MB
Intel Core i5-7500 compare3400 - 3800 MHz4 / 46 MB
Intel Core i5-7440HQ compare2800 - 3800 MHz4 / 46 MB
Intel Core i7-7567U compare3500 - 4000 MHz2 / 44 MB
Intel Core i7-7660U compare2500 - 4000 MHz2 / 44 MB
Intel Core i7-7600U compare2800 - 3900 MHz2 / 44 MB
Intel Core i5-7300HQ compare2500 - 3500 MHz4 / 46 MB
Intel Core i5-7500T compare2700 - 3300 MHz4 / 46 MB
Intel Core i5-7287U compare3300 - 3700 MHz2 / 44 MB
» Intel Core i7-7560U2400 - 3800 MHz2 / 44 MB
Intel Core i5-7360U compare2300 - 3600 MHz2 / 44 MB
Intel Core i5-7267U compare3100 - 3500 MHz2 / 44 MB
Intel Core i7-7500U compare2700 - 3500 MHz2 / 44 MB
Intel Core i5-7300U compare2600 - 3500 MHz2 / 43 MB
Intel Core i5-7260U compare2200 - 3400 MHz2 / 44 MB
Intel Core i5-7200U compare2500 - 3100 MHz2 / 43 MB
Intel Core i3-7100H compare3000 MHz2 / 43 MB
Intel Core i3-7167U compare2800 MHz2 / 43 MB
Intel Core i3-7130U compare2700 MHz2 / 43 MB
Intel Core i7-7Y75 compare1300 - 3600 MHz2 / 44 MB
Intel Core i5-7Y57 compare1200 - 3300 MHz2 / 44 MB
Intel Core i5-7Y54 compare1200 - 3200 MHz2 / 44 MB
Intel Core i3-7100U compare2400 MHz2 / 43 MB
Intel Core m3-7Y321000 - 3000 MHz2 / 44 MB
Intel Pentium Gold 4415U compare2300 MHz2 / 42 MB
Intel Core m3-7Y30 compare1000 - 2600 MHz2 / 44 MB
Intel Celeron 3965U compare2200 MHz2 / 22 MB
Intel Core i3-7020U compare2300 MHz2 / 43 MB
Intel Celeron 3867U compare1800 MHz2 / 22 MB
Intel Celeron 3865U compare1800 MHz2 / 22 MB
Intel Pentium Gold 4425Y compare1700 MHz2 / 42 MB
Intel Pentium Gold 4415Y compare1600 MHz2 / 42 MB
Intel Pentium Gold 4410Y compare1500 MHz2 / 42 MB
Intel Celeron 3965Y compare1500 MHz2 / 22 MB
1000 - 3000 MHz2400 - 3800 MHz
128 KB128 KB
512 KB512 KB
4 MB4 MB
2 / 42 / 4
4.5 15
14 14
100 °C100 °C
BGABGA1356
Dual-Channel DDR3L-1600/LPDDR3-1866 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, TXTDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
iGPUIntel HD Graphics 615 (300 - 900 MHz)Intel Iris Plus Graphics 640 (300 - 1050 MHz)
$281 U.S.$415 U.S.
Intel Kaby Lake m3-7Y32

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
265 Points (6%)
336 Points (8%)
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
120 Points (52%)
153 Points (67%)
3DMark 11 - 3DM11 Performance Physics
2747 Points (12%)
4693 Points (21%)
3DMark - 3DMark Cloud Gate Physics
2606 Points (7%)
3651 Points (9%)

Average Benchmarks Intel Core m3-7Y32 → 100% n=4

Average Benchmarks Intel Core i7-7560U → 141% n=4

-
-
* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation
