Intel Core i5-7260U vs Intel Core i7-7Y75
Intel Core i5-7260U► remove from comparison
The Intel Core i5-7260U is a fast dual-core SoC for notebooks and Ultrabooks based on the Kaby Lake architecture and was announced in January 2017. The CPU has two processor cores clocked at 2.2-3.4 GHz (two cores also up to 3.4 GHz). The processor can execute up to four threads simultaneously thanks to Hyper Threading. It is also equipped with an Intel Iris Plus Graphics 640 GPU with 64 MB eDRAM, a dual-channel memory controller (DDR4) as well as VP9 and H.265 video decoding as well as encoding. The chip is still manufactured in a 14nm process with FinFET transistors.
Compared to the Core i7-7360U, the i5-7260 does have lower CPU (-200 MHz Turbo, -100 MHz Base) and GPU (-50 MHz) clocks.
Intel basically uses the same micro architecture compared to Skylake, so the per-MHz performance does not differ. The manufacturer only reworked the Speed Shift technology for faster dynamic adjustments of voltages and clocks, and the improved 14nm process allows much higher frequencies combined with better efficiency than before.
At 2.2-3.4 GHz, the Core i5-7260U has much lower clocks compared to the old Core i5-6267U (2.9-3.3 GHz), but has slightly higher Turbo clocks. Similar to the 6267U, the i6-7260U can also use the 64 MB eDRAM, which should increase the performance in some scenarios.
The integrated Intel Iris Plus 640 Graphics is the GT3e model of the Kaby Lake GPU (Intel Gen. 9.5). It has 48 Execution Units running at 300-950 MHz (i7 models up to 1050 MHz) and the performance is comparable to a GeForce 920MX thanks to fast eDRAM cache. However, there aren't any significant improvements compared to the old Iris Pro 540, so modern games can often not be played smoothly or only at the lowest or medium settings, respectively.
Contrary to Skylake, Kaby lake now also supports H.265/HEVC Main 10 with a 10-bit color depth as well as Google's VP9 codec. The dual-core Kaby Lake processors announced in January should also support HDCP 2.2.
The chip is manufactured in an improved 14nm process with FinFET transistors, which improves the efficiency even further. Intel still specifies the TDP with 15 Watts, which is typical for ULV chips. Depending on the usage scenario, the TDP can vary between 7.5 (cTDP Down) and 25 Watts.
Intel Core i7-7Y75► remove from comparison
The Intel Core i7-7Y75 is a very efficient dual-core SoC for tablets and passively cooled notebooks based on the Kaby Lake architecture and was announced in the end of August 2016. The CPU consists of two processor cores clocked at 1.3-3.6 GHz (2-core Turbo not specified yet). Thanks to Hyper Threading, the processor can execute up to four threads simultaneously. The chips also includes the Intel HD Graphics 615 GPU, a dual-channel memory controller (DDR3L/LPDDR3) as well as VP9 and H.265 video de- and encoder. It is still produced in a 14 nm process with FinFET transistors.
Intel basically used the familiar micro architecture from the Skylake generation, so the per-MHz performance is identical. Only the Speed-Shift technology for faster dynamic adjustments of the voltages and clocks was improved, and the matured 14 nm process now also enables much higher frequencies and better efficiency than before.
Despite the changed designation, the Core i7-7Y75 is the successor to the Core m7-6Y75 (Skylake Y-series), so the chip does not reach the performance level of other Core i processors due to the lower TDP. Thanks to its high Turbo clock, the 7Y75 can sometimes keep up with the 15 Watt models for short peak load and single-thread scenarios, but the clocks will drop significantly under sustained workloads. The CPU is still suitable for many more demanding applications as well as multitasking.
The integrated Intel HD Graphics 615 GPU has 24 Execution Units (EUs) like the old HD Graphics 515 and runs with clocks between 300 and 1050 MHz in combination with this processor. The performance heavily depends on the TDP limit as well as the memory configuration; with fast LPDDR3-1866 RAM in dual-channel mode, the GPU should sometimes be able to compete with the HD Graphics 520, but can also be much slower in other scenarios. Modern games from 2016 will, if at all, only run smoothly in the lowest settings.
Contrary to Skylake, Kaby Lake now also supports hardware decoding for H.265/HEVC Main10 with a 10-bit color depth as well as Google's VP9 codec.
The chip is manufactured in an improved 14 nm process with FinFET transistors, so the power efficiency was once again improved significantly. The typical TDP for the Y-series is specified at 4.5 Watts, and can be adjusted in both directions depending on the usage scenario.
|Model||Intel Core i5-7260U||Intel Core i7-7Y75|
|Series||Intel Kaby Lake||Intel Kaby Lake|
|Codename||Kaby Lake||Kaby Lake|
|Series: Kaby Lake Kaby Lake|
|Clock||2200 - 3400 MHz||1300 - 3600 MHz|
|L1 Cache||128 KB||128 KB|
|L2 Cache||512 KB||512 KB|
|L3 Cache||4 MB||4 MB|
|Cores / Threads||2 / 4||2 / 4|
|TDP||15 Watt||4.5 Watt|
|Technology||14 nm||14 nm|
|max. Temp.||100 °C||100 °C|
|Features||Dual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI||Dual-Channel DDR3L-1600/LPDDR3-1866 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT|
|iGPU||Intel Iris Plus Graphics 640 (300 - 950 MHz)||Intel HD Graphics 615 (300 - 1050 MHz)|
|$304 U.S.||$393 U.S.|
|Manufacturer||Intel Kaby Lake i5-7260U||Intel Kaby Lake i7-7Y75|
