The Mediatek Helio X20 MT6797 is an upper mainstream ARM SoC for smartphones (mainly Android based) that was introduced in 2016. It is manufactured in a 20 nm process and is equipped with 10 CPU cores. Two fast Cortex-A72 cores are running at up to 2.3 GHz, four Cortex-A53 cores at up to 1.83 GHz and four Cortex-A53 cores at up to 1.4 GHz. All cores support 64-bit and the utilization of three clusters is supposed to improve efficiency according to Mediatek. The two A72 cores are only designed for short "Burst-Performance scenarios" according to Mediatek and are probably not used for sustained workloads.
The integrated ARM Mali T880 MP4 (according to Wikipedia) GPU is clocked at up to 780 MHz and has four cluster (from 16) from the Midgard (4th Gen) architecture.
The chip also includes an LTE modem (Cat. 6 300/50 Mbps, DC-HSPA+, TD-SCDMA, EDGE, CDMA2000, ...) as well as a WLAN 802.11ac (280 Mbps) modem. GPS/Glonass/BeiDou is supported for location. The integrated video encoder can handle up to 4Kx2K H.265 at 30 fps and HDR. The SoC can also decode H.265, H.264 and VP9 in 4K30.
Power Consumption
The processor is manufactured in a 20 nm process at TSMC and should have an average power consumption under load.
| Series | Mediatek Mediatek Helio 20 | ||||||||
| Codename | Cortex-A72 / A53 | ||||||||
Series: Mediatek Helio 20 Cortex-A72 / A53
| |||||||||
| Clock Rate | 2300 MHz | ||||||||
| Number of Cores / Threads | 10 / 10 | ||||||||
| Manufacturing Technology | 20 nm | ||||||||
| Features | UMTS/HSPA+, LTE Cat. 6, TD-SCDMA, 802.11ac WiFi, Dual-Channel LPDDR3-1866 Memory Controller, eMMC 5.1, [email protected] H.265 Video Encoder, H.265 [email protected] Decode, ARM Mali 780 MHz | ||||||||
| GPU | ARM Mali-T880 MP4 ( - 780 MHz) | ||||||||
| 64 Bit | 64 Bit support | ||||||||
| Architecture | ARM | ||||||||
| Announcement Date | 03/01/2016 | ||||||||
| Product Link (external) | Mediatek Mediatek Helio 20 Helio X20 MT6797 | ||||||||
