Mediatek MT8735 vs Mediatek MT6735M vs Mediatek MT8752
Mediatek MT8735► remove from comparison
The Mediatek MT8735 is a mid range ARM based SoC for (mostly Android based) smartphones. It was manufactured in 28nm and offers a quad-core processor with four ARM Cortex-A53 cores clocked at up to 1.3 GHz. As a graphics card, the SoC integrates a ARM MAli-T720MP2. The integrated LTE radio supports CDMA2000 and a 5GHz 802.11bgn WiFi modem is also included.
Mediatek MT6735M► remove from comparison
The 1.5 GHz MediaTek MT6735M is a 64-bit ARM-based SoC launched in mid 2015 primarily for small budget to mainstream Android devices. The quad-core processor is manufactured in 28 nm and is based on the Cortex-A53 architecture. It integrates a cat.4 LTE modem with CDMA2000 and an ARM Mali-720 GPU capable of decoding and encoding videos of up to 1080p30. Compared to the MT6732, the MT6735M utilizes a slower graphics unit. Compared to the similar MediaTek MT6735, the "M"-version is significantly lower clocked (only 1 versus 1.5 GHz).
The Cortex-A53 is the successor to the popular Cortex-A7 design. In addition to the jump from 32-bit to 64-bit architecture (ARMv8 ISA) to address more than 4 GB of memory, the new design offers better branch prediction and higher performance-to-power ratio that rivals the Cortex-A9. The four cores of the MT6732 are clocked at up to 1 GHz and therefore the MT6735M is significantly slower than other A53 SoCs that are usually clocked at 1.4 GHz and up.
The power-efficient processor is still suited for low demanding tasks like browsing and running light applications.
The integrated single-core Mali-T720 is an entry-level GPU clocked at up to 450 MHz. Most Android games will play at acceptable frame rates on medium resolutions and quality.
The MT6732M SoC integrates a memory controller (32-bit LPDDR3, 6.4 GB/s), multiple radios (WLAN, Bluetooth, GPS), and a cellular modem (GSM, UMTS, GPRS, HSPA+, HSUPA, TD-SCDMA, EVDO, and LTE Cat 4). Its integrated video engine allows for 1080p playback at 30 FPS. Cameras are supported up to 13 MP.
Mediatek MT8752► remove from comparison
The MediaTek MT8752 is a ARM based SoC for mostly Android based tablets and smartphones. It integrates 8 small ARM Cortex-A53 cores at up to 1.7 GHz. The integrated graphics card is an ARM Mali-T760MP2 with up to 700 MHz clock speed. Furthermore, an LTE modem and a video de- and encoder are integrated in the chip.
|Model||Mediatek MT8735||Mediatek MT6735M||Mediatek MT8752|
|Series: Mediatek Cortex-A53|
|Clock||1300 MHz||1000 MHz||1700 MHz|
|Cores / Threads||4 / 4||4 / 4||8 / 8|
|Technology||28 nm||28 nm||28 nm|
|Features||4G FDD LTE, TDD LTE, HSPA+, TD-SCDMA, CDMA200 and EDGE, Dual-band Wi-Fi, Bluetooth 4.0, 16MP image signal-processor, 1280x800 display, FM receiver, GPS/Glonass/Baidou||Rel. 9, Cat. 4 LTE (FDD & TDD), DC-HSPA+, TD-SCDMA, CDMA2000 1x/EVDO Rev. A, EDGE, 802.11n Wi-Fi, Bluetooth 4.0, 13MP image signal-processor,||4G LTE (Cat. 4), HSPA+, TD-SCDMA, EDGE, WLAN (2,4 + 5 GHz), Bluetooth, GPS, FM receiver, H.265 Decoder, ARM Mali-T760 MP2 GPU|
|iGPU||ARM Mali-T720||ARM Mali-T720 ( - 450 MHz)||ARM Mali-T760 MP2 ( - 700 MHz)|
|Manufacturer||Mediatek MT8735||Mediatek MT8752|
