The MediaTek MT6739WW is a 64-bit ARM-based SoC launched in 2017 primarily for small budget Android devices. The quad-core processor is based on the Cortex-A53 architecture and clocks up to 1.5 GHz. It integrates an LTE modem (Cat. 4 DL / Cat 5 UL) and a PowerVR GE8100 at 570 MHz (the predecessors used ARM Mali GPUs). Furthermore, the SoC integrates a 802.11 a/b/g/n Wi-Fi adapter and a video de- and encoder in hardware.
The difference to the normal Mediatek MT6739 (see for more benchmarks) is not known and specs and performance are identical.
The ARM-based Mediatek MT6750T SoC (System on a Chip) is a mid-range mobile processor announced in Q2 2016 for smartphones and tablets (mostly Android based). It integrates 8 ARM Cortex-A53 cores consisting of 4 high-performance cores clocked at up to 1.5 GHz plus 4 low-power cores clocked at up to 1 GHz each. Furthermore, the SoC integrates a Cat. 6 LTE radio and an ARM Mali-T860 MP2 GPU with 802.11n WiFi and Bluetooth connectivity. The difference to the MT6750 is not clear.
The Cortex-A53 is the successor to the Cortex-A7 and introduces 64-Bit support (ARMv8-ISA). Its performance-per-Watt is significantly higher and is even slightly ahead of the old Cortex-A9. If utilizing all 8 of its cores, the Cortex-A53 can rival competing mobile processes in the high-end class range. However, no practical software has been specifically coded to use all 8 cores at such high performance levels.
The integrated GPU is the modern ARM Mali-T860 MP2 (two clusters) clocked at up to 520 MHz. It should be able to run all current Android games.
In addition to the CPU and GPU cores, the SoC also contains a memory controller and the aforementioned Cat.6 LTE modem (FDD/TDD, DC-HSPA+, TD-SCDMA, CDMA2000, EDGE) with both 802.11n WiFi and Bluetooth. The integrated video engine is able to record and playback 1080p videos at up to 30 FPS in hardware. Cameras are supported at up to 16 MP.
The MT6750 is still manufactured in 28nm and so power efficiency is not on par with modern 14/16nm chips.
The MediaTek MT6737T is a 64-bit ARM-based SoC announced in 2016 primarily designed for smartphones (mainly Android devices). It is manufactured in a 28 nm process and consists of four CPU cores based on the 64-bit Cortex-A53 architecture clocked at up to 1.5 GHz (MT6737 up to 1.35 GHz). The GPU is an ARM Mali-720 MP2. It integrates a Cat.4 LTE modem with CDMA2000 as well as a video de- and encoder for 1080p30 videos (H.264 and H.265).
The Cortex-A53 is the successor to the popular Cortex-A7 design. In addition to the jump from 32-bit to 64-bit architecture (ARMv8 ISA) to address more than 4 GB of memory, the new design offers better branch prediction and higher performance-to-power ratio that rivals the Cortex-A9. The four cores of the MT6737 are clocked at up to 1.5 GHz and are roughly on par with the Snapdragon 410 (4x Cortex-A53 at 1.2 to 1.4 GHz). The processor is fit for common tasks like browsing and running light applications.
The integrated single-core Mali-T720 is an entry-level GPU clocked between 550-650 MHz for the MT6737 (or 600 for the MT6737T). Most Android games will play at acceptable frame rates on low or medium resolutions and quality.
Besides CPU and GPU, the MT6737T SoC also integrates a memory controller (1x LPDDR2/3 733 MHz), multiple radios (WLAN, Bluetooth, GPS), and a cellular modem (GSM, UMTS, GPRS, HSPA+, HSUPA, TD-SCDMA, EVDO, and LTE Cat 4). Its integrated video engine allows for 1080p playback at 30 FPS. Cameras are supported up to 13 MP.
