Qualcomm Snapdragon 670 vs Qualcomm Snapdragon 805 APQ8084

Qualcomm Snapdragon 670

The Qualcomm Snapdragon 670 (SD670) is a fast mid-range ARM-based SoC largely found on Android tablets and smartphones. Announced late 2018, the SD670 is the successor to the Snapdragon 660. It features 8 Kryo 360 cores (custom design, 64-Bit capable) that are divided in two clusters. A fast cluster of two cores with up to 2 GHz and a power saving efficiency cluster with up to 1.7 GHz. Both clusters can also used together.

In addition to the 8 CPU cores, the SoC integrates a mid range Adreno 616 GPU with a LPDDR4X-3733 memory controller (dual-channel 1867 MHz) and supports Wi-Fi (802.11ac + MIMO, max. 867 Mbps), Bluetooth 5, and LTE (X12 LTE modem with up to 600 Mbps download and 150 Mbps upload).

Performance

In Benchmarks the Snapdragon 670 is slightly faster than the old Snapdragon 660 and therefore a solid mid-range processor.

CPU

The Snapdragon 660 is based on a similar concept as ARM's big.LITTLE, which combines a low power CPU cluster (2x Kyro clocked at up to 1.8 GHz) and a performance CPU cluster (2x Kyro clocked at up to 2.2 GHz). The clock speed of each cluster can be individually adjusted (but not per core) and the lowest clock speed is 310 MHz (unverified).

Power Consumption

Thanks to the new 10 nm LPP process at Samsung, the energy efficiency has been improved noticeably compared to its 14 nm predecessors.

Qualcomm Snapdragon 805 APQ8084

The Qualcomm Snapdragon 805 (APQ8084) is an ARM-based SoC largely for Android tablets and smartphones. Announced in November 2013, the S805 is the successor to the Snapdragon 801, making it the new top model among the ARM SoCs from Qualcomm. In addition to the slightly improved quad-core CPU (2.7 GHz vs. 2.5 GHz S801), the SoC integrates a brand-new GPU. The Adreno 420 offers new features like DirectX 11 and outperforms its predecessor by up to 40 percent. Furthermore, the chip integrates a 128-bit memory controller (LPDDR3-1600, 25.6 GB/s) and supports both Wi-Fi (802.11a/b/g/n/ac) and Bluetooth 4.1. UMTS and LTE(+) can be added by an additional radio (e.g. Gobi MDM 9x35).

CPU

The CPU cores have been modified just slightly and are now based on the Krait 450 architecture (performance per clock between Cortex-A7/A9 and Cortex-A15 or Apple Cyclone). This also means that the cores are still based on the ARMv7 ISA, which is a 32-bit design. Competitors like Apple are already selling 64-bit-capable ARMv8 chips, e.g. the Apple A8  and A8X as found on the iPhone 6 and iPad Air 2. Thanks to its quad-core design and very high clock rates of up to 2.7 GHz, the Snapdragon 805 offers a performance similar to the Samsung Exynos 5433 and is therefore one of the fastest ARM-based SoCs of 2014.

GPU

The new Adreno 420 graphics unit not only supports DirectX 11.1 (and therefore new features such as tessellation), but will also provide an up to 40 percent 3D performance boost compared to the previous Adreno 330. Overall, the Adreno 420 (usually clocked at 600 MHz) is somewhat faster than the Mali-T628 MP6 (Samsung Exynos 5420/5430) and PowerVR G6430 (Apple A7). Only Nvidia's Tegra K1 and the PowerVR GX6650 (Apple A8X) are offering an even higher performance.

Features

As the Snapdragon 805 does not have a cellular modem, an additional module must be installed for use in smartphones. Qualcomm provides either the Gobi MDM9x25 or MDM9x35 series, both of which include support for UMTS, LTE(+) Cat. 4 and carrier aggregation.

The Snapdragon 805 is one of the first SoCs available to be able to decode 4k videos with the H.265 codec and stream the content to a compatible TV. A large number of older video codecs are also supported.

The revised camera ISP is now even more powerful than before and can handle a throughput in the GPixel/s range. This allows advanced post-processing capabilities as well as cameras with higher resolutions.

Power Consumption

The Snapdragon 805 is manufactured by TSMC in a 28-nanometer HPM process. The power consumption should be approximately in the range of its predecessor, which we have estimated at about 3 - 5 W. The full performance will only be achieved in larger tablets as they can tolerate higher temperatures generally better than smaller smartphones.
