The Qualcomm Snapdragon 610 MSM8936 is a mid-range ARMv8-based SoC largely for Android tablets and smartphones. Announced in February 2014, the S610 is one of the first 64-bit capable SoCs from Qualcomm. In addition to 4 Cortex-A53 CPU cores at up to 1.7 GHz, the SoC integrates an Adreno 405 GPU with a 2x 32-bit memory controller (LPDDR3-1600, 12.8 GB/s) and supports Wi-Fi (802.11ac), Bluetooth 4.0, UMTS and LTE.
The Cortex-A53 is the successor to the very popular Cortex-A7 design. In addition to the new 64-bit capable ARMv8 ISA, the cores offer a variety of other improvements such as better branch prediction. This leads to a significantly higher performance per clock, which is even above the older Cortex-A9.
The four cores of the Snapdragon 610 are clocked at up to 1.7 GHz, offering a performance similar to that of the older Snapdragon 600 (Krait architecture).
Another new feature is the integrated graphics unit named Adreno 405 (550 MHz). The Adreno 400 series has been substantially redesigned and supports DirectX 11.2 (FL 11_1) including hardware tessellation, OpenGL ES 3.1, and OpenCL 1.2. Furthermore, the performance has been significantly improved, which is now similar to the Adreno 320 and PowerVR G6200.
The Snapdragon 610 offers numerous wireless technologies such as Bluetooth 4.0 and WLAN 802.11a/b/g/n/ac as well as a Multi-SIM cellular modem supporting LTE cat. 4 (up to 150 Mbps), WCDMA, CDMA, EV-DO, TD-SCDMA and GSM/EDGE.
The SoC can encode and decode 1080p videos using dedicated hardware and stream content to displays with up to 2560 x 1600 pixels. A large number of video codecs including H.265 (playback only) will be supported. The camera ISP can handle sensors with up to 21 MP.
The Snapdragon 610 is manufactured by TSMC in a 28 nm LP process. According to the specifications, we expect a medium power consumption for use in medium-sized smartphones and tablets.
The Qualcomm Snapdragon 450 (SD450) is a lower mainstream SoC for (Android based) smartphones and tablets. It features eight ARM Cortex-A53 cores at up to 1.8 GHz and is already manufactured in the power efficient 14nm process. The integrated X9 LTE modem supports Cat. 7 with maximum transfer rates of 300 Mbps (downstream) and 150 Mbps (upstream). The SoC also includes an Adreno 506 GPU with support for Vulkan and OpenGL ES 3.1. WiFi 802.11ac (1x1, max 364 Mbps) and Bluetooth 4.1 are supported as well. The memory controller supports LPDDR3 (single channel) and the integrated video engine supports H.264 (encode and decode) and HEVC (only decode) in 1080p.
The Qualcomm Snapdragon 626 (SD626) is a mid-range octa-core SoC with eight ARM Cortex-A53 cpu cores at up to 2.2 GHz, an Adreno 506 GPU, a DDR3L-1866 memory controller and a X9 LTE (Cat 7, 4G+, 300 Mbps down, 150 Mbps up) modem. Furthermore, the chip supports 802.11ac WiFi and Bluetooth 4.1. It is manufactured in 14nm FinFet. The processor performance should be a bit higher than the average Snapdragon 625, due to the 200 MHz higher maximum clock speed.
Average Benchmarks Qualcomm Snapdragon 450 → NAN%n=
Average Benchmarks Qualcomm Snapdragon 626 → NAN%n=
- Range of benchmark values for this graphics card - Average benchmark values for this graphics card * Smaller numbers mean a higher performance 1 This benchmark is not used for the average calculation
