Samsung Exynos 4210 1.2 GHz vs Samsung Exynos 4210 1.4 GHz vs Samsung Exynos 4412 Quad
Samsung Exynos 4210 1.2 GHz► remove from comparison
The Samsung Exynos 4 Dual (formerly known as Exynos 4210) is a dual-core Cortex-A9 based SoC with a ARM Mali-400 MP4 graphics card. Clocked at 1.2 GHz (CPU), the 4210 was used in the Galaxy S II and Galaxy Tab 7.0 Plus.
Samsung Exynos 4210 1.4 GHz► remove from comparison
The Samsung Exynos 4 Dual (formerly known as Exynos 4210) is a dual-core Cortex-A9 based SoC with a ARM Mali-400 MP4 graphics card. Clocked at 1.4 GHz (CPU), the 4210 was used in the Galaxy Note, Galaxy Tab 7.7 and Meizu MX. The 1.2 GHz version can be found here.
Samsung Exynos 4412 Quad► remove from comparison
The Samsung Exynos 4 Quad (also called Exynos 4412, introduced in 2012) is an ARM SoC for tablets and smartphones. It includes a quad-core processor based on the Cortex-A9 architecture (including NEON SIMD extension), which clocks with 1.4 to 1.6 GHz (depending on the model). Thus, the computing power is similar to competitors like Nvidia's Tegra 3 SoC. The memory controller supports LPDDR2, DDR2 and DDR3 with a maximum of two 32-bit channels and 400 MHz clock speed, resulting in a bandwidth of up to 6.4 GB/s.
The SoC integrates an ARM Mali-400 MP4 GPU (15.8 GFLOPS at 440 MHz). Typical smartphone games (2012) will run fluently even in high resolutions like 1280 x 720 pixels. Videos can be accelerated by a multi-format video decoder (1080p AVI, WMV, H.264, H.263, VC1, MPEG2, MPEG4).
The chip is produced in Samsung fabs in 32nm HKMG and mainly found in high-end devices like the Samsung Galaxy S3 or Note 2. Depending on the clock speed, the power consumption should be between 2 and 4 W (estimated).
|Model||Samsung Exynos 4210 1.2 GHz||Samsung Exynos 4210 1.4 GHz||Samsung Exynos 4412 Quad|
|Series||Samsung Exynos||Samsung Exynos||Samsung Exynos|
|Codename||Cortex A9||Cortex A9||Cortex A9|
|Series: Exynos Cortex A9|
|Clock||1200 MHz||1400 MHz||1400 - 1600 MHz|
|L1 Cache||128 KB||128 KB|
|L2 Cache||1 MB||1 MB|
|Cores / Threads||2 / 2||2 / 2||4 / 4|
|Technology||45 nm||45 nm||32 nm|
|Features||NEON, Mali 400MP, Memory Controller||NEON, Mali 400MP, Memory Controller||NEON, Mali 400MP4, Memory Controller|
|Manufacturer||Samsung Exynos 4210 1.2 GHz||Samsung Exynos 4210 1.4 GHz||Samsung Exynos 4412 Quad|
