NVIDIA GeForce GT 745M

NVIDIA GeForce GT 745M

The NVIDIA GeForce GT 745M is a DirectX 11 graphics card of the middle class. It is based on the Kepler architecture and manufactured by TSMC in a 28-nanometer process. The GK107 chip (384 shaders) is clocked at up to 837 MHz plus boost and has a 128 bit memory interface (usually DDR3, but GDDR5 also possible).

Architecture

The GK107 Kepler core offers two shader blocks, called SMX, each with 192 shaders for a total of 384 shader cores that are clocked at the same speed as the processor core. Although more shader cores are available in the Kepler architecture as compared to the Fermi design, the Kepler shaders are expected to be up to two times more power efficient. However, due to the missing hot clock of the shader domain, two shaders of a Kepler chip are as fast as one shader of a Fermi chip, even though Fermi shaders are clocked at twice the speed.

PCIe 3.0 is now supported by the mobile Kepler series and GPU Boost 2.0 can automatically overclock the card if the laptop cooling system allows it. This feature is available on any notebook with a graphics card of the 700M series.

Performance

Depending on clock speed and memory configuration, the GT 745M performs just below the GT 650M or GTX 660M. Models with GDDR5 memory are usually slightly faster than models with DDR3. Current games (as of 2013) can be played fluently in medium to high settings. In older titles, there are also reserves for additional quality features like AA and AF.

Features

The feature set includes support for up to 4 active displays. Furthermore, high resolution monitors of up to 3840x2160 pixels can now be connected using DisplayPort 1.2 or HDMI 1.4a if available. HD-Audio codecs, such as Dolby TrueHD and DTS-HD, can be transmitted via bitstream mode through the HDMI port. However, as most laptops will feature Optimus, the integrated GPU will likely have direct control over the display ports and may limit the feature set available by the Nvidia Kepler cards.

The 5th generation PureVideo HD video processor (VP5) (also integrated in the GK107 core) offers hardware decoding of HD videos. Common codecs such as MPEG-1/2, MPEG-4 ASP, H.264 and VC1/WMV9 are fully supported up to 4K resolutions while VC1 and MPEG-4 are supported up to 1080p. Two streams can be decoded in parallel for features such as Picture-in-Picture. Another feature is the inclusion of a dedicated video encoding engine similar to Intel QuickSync that can be accessed via the NVENCI API.

Power Consumption

The power consumption of the GeForce GT 745M should be similar to the GT 645M (about 25 - 30 watts). As a result, the Nvidia GPU is best suited for multimedia notebooks 14-inches in size or greater.

ManufacturerNVIDIA
GeForce GT 700M Series

GeForce GT 755M SLI

768 @ 980 MHz128 Bit @ 5400 MHz

GeForce GT 750M SLI

768 @ 967 MHz128 Bit @ 2000 - 5000 MHz

GeForce GT 755M

384 @ 980 MHz128 Bit @ 5400 MHz

GeForce GT 750M

384 @ 967 MHz128 Bit @ 2000 - 5000 MHz
GeForce GT 745M 384 @ 837 MHz128 Bit @ 1800 MHz

GeForce GT 740M

384 @ 810 - 980 (Boost) MHz64/128 Bit @ 1600 - 1800 MHz

GeForce GT 735M

384 @ 575 - 889 (Boost) MHz64 Bit @ 1800 - 2000 MHz

GeForce GT 730M

384 @ 725 MHz64/128 Bit @ 1800 - 2000 MHz

GeForce GT 720M

96 @ 625 - 938 (Boost) MHz64 Bit @ 1800 - 2000 MHz
CodenameN14P-LP/GS
ArchitectureKepler
Pipelines384 - unified
Core Speed *837 MHz
Memory Speed *1800 MHz
Memory Bus Width128 Bit
Memory TypeDDR3, GDDR5
Max. Amount of Memory2048 MB
Shared Memoryno
DirectXDirectX 11, Shader 5.0
Transistors1300 Million
technology28 nm
FeaturesOptimus, GPU Boost 2.0, PhysX, Verde Drivers, CUDA, 3D Vision, 3DTV Play
Notebook Sizemedium sized
Date of Announcement01.04.2013
* The specified clock rates are only guidelines for the manufacturer and can be altered by them.

Benchmarks

Cinebench R15 - Ref. Match 64Bit
0% 100%
min: 99.6      avg: 99.6 (100%)     median: 99.6 (100%)     max: 99.6 Points
Cinebench R15 - OpenGL 64Bit
0% 100%
min: 53.25      avg: 58.3 (49%)     median: 56.7 (47%)     max: 64.62 Points
3DMark (2013) - Fire Strike Standard Graphics 1920x1080
0% 100%
min: 1301      avg: 1480 (12%)     median: 1531 (13%)     max: 1592 Points
3DMark (2013) - Cloud Gate Standard Graphics 1280x720
0% 100%
min: 7867      avg: 9861.6 (13%)     median: 10147 (13%)     max: 11036 Points
3DMark (2013) - Ice Storm Standard Graphics 1280x720
0% 100%
min: 38674      avg: 70074.8 (9%)     median: 73947 (10%)     max: 85284 Points
ComputeMark v2.1 - Normal, Score 1024x600
0% 100%
min: 1559      avg: 1559 (27%)     median: 1559 (27%)     max: 1559 Points
LuxMark v2.0 64Bit - Room Scene, OpenCL GPUs-only
0% 100%
min: 225      avg: 225 (15%)     median: 225 (15%)     max: 225 Samples/s
3DMark 11 - Performance GPU 1280x720
0% 100%
min: 1936      avg: 2213.4 (14%)     median: 2249 (14%)     max: 2390 points
3DMark 11 - Performance 1280x720
0% 100%
min: 2016      avg: 2345.8 (18%)     median: 2407 (18%)     max: 2542 points
3DMark Vantage - P GPU no PhysX 1280x1024
0% 100%
min: 7526      avg: 7630.7 (17%)     median: 7615 (16%)     max: 7751 Points
3DMark Vantage - P Result no PhysX 1280x1024
0% 100%
min: 8996      avg: 9109 (23%)     median: 9045 (23%)     max: 9286 Points
3DMark 06
0% 100%
min: 8737      avg: 12350.8 (41%)     median: 13462.5 (45%)     max: 13741 Points
3DMark 05 - Standard 1024x768
0% 100%
min: 21505      avg: 21505 (58%)     median: 21505 (58%)     max: 21505 Points
Unigine Heaven 2.1 - high, Tesselation (normal), DirectX11 1280x1024
0% 100%
min: 25.4      avg: 25.4 (14%)     median: 25.4 (14%)     max: 25.4 fps
PCMark Vantage - Gaming Score 1024x768
0% 100%
min: 7344      avg: 7588.5 (29%)     median: 7588.5 (29%)     max: 7833 Points
SPECviewperf 11 - Siemens NX 1920x1080
0% 100%
min: 2.88      avg: 2.9 (5%)     median: 2.9 (5%)     max: 2.88 fps
SPECviewperf 11 - Tcvis 1920x1080
0% 100%
min: 0.92      avg: 0.9 (2%)     median: 0.9 (2%)     max: 0.92 fps
SPECviewperf 11 - SolidWorks 1920x1080
0% 100%
min: 8.47      avg: 8.5 (13%)     median: 8.5 (13%)     max: 8.47 fps
SPECviewperf 11 - Pro/ENGINEER 1920x1080
0% 100%
min: 1.37      avg: 1.4 (7%)     median: 1.4 (7%)     max: 1.37 fps
SPECviewperf 11 - Maya 1920x1080
0% 100%
min: 9.88      avg: 9.9 (9%)     median: 9.9 (9%)     max: 9.88 fps
SPECviewperf 11 - Lightwave 1920x1080
0% 100%
min: 17.33      avg: 17.3 (21%)     median: 17.3 (21%)     max: 17.33 fps
SPECviewperf 11 - Ensight 1920x1080
0% 100%
min: 17.21      avg: 17.2 (21%)     median: 17.2 (21%)     max: 17.21 fps
SPECviewperf 11 - Catia 1920x1080
0% 100%
min: 7.53      avg: 7.5 (11%)     median: 7.5 (11%)     max: 7.53 fps
Cinebench R11.5 - OpenGL 64Bit
0% 100%
min: 36.27      avg: 45.9 (42%)     median: 49.5 (45%)     max: 52.02 Points
Cinebench R10 - Shading 32Bit
0% 100%
min: 6532      avg: 6748.3 (56%)     median: 6788.5 (56%)     max: 6884 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

Thief

Thief

2014
low 1024x768
27.9  fps      Compare
med. 1366x768
19.9  fps      Compare
high 1366x768
17.1  fps      Compare
ultra 1920x1080
9.5  fps      Compare
» The benchmarks indicate that the game is not playable in the tested settings.
X-Plane 10.25
low 1024x768
71.1  fps      Compare
med. 1366x768
33.7  fps      Compare
high 1366x768
16.7  fps      Compare
» With all tested laptops playable in detail settings low.
Need for Speed: Rivals
low 1024x768
30  fps      Compare
med. 1366x768
30  fps      Compare
high 1366x768
27  fps      Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield 4
med. 1366x768
45.8  fps      Compare
high 1366x768
28.9  fps      Compare
ultra 1920x1080
11.2  fps      Compare
» With all tested laptops playable in detail settings med..
Batman: Arkham Origins
low 1024x768
132  fps      Compare
med. 1366x768
77  fps      Compare
high 1366x768
36  fps      Compare
ultra 1920x1080
17  fps      Compare
» With all tested laptops playable in detail settings high.
F1 2013

F1 2013

2013
med. 1366x768
105  fps      Compare
high 1366x768
94  fps      Compare
ultra 1920x1080
38  fps      Compare
» With all tested laptops playable in detail settings ultra.
Fifa 14

Fifa 14

2013
low 1024x768
279.4  fps      Compare
med. 1366x768
222.4  fps      Compare
high 1366x768
199.5  fps      Compare
ultra 1920x1080
134.1  fps      Compare
» With all tested laptops playable in detail settings ultra.
Total War: Rome II
med. 1366x768
66.3  fps      Compare
high 1366x768
53.4  fps      Compare
ultra 1920x1080
7.9  fps      Compare
» With all tested laptops playable in detail settings high.
Saints Row IV
med. 1366x768
52.1  fps      Compare
high 1366x768
22.3  fps      Compare
» With all tested laptops playable in detail settings med..
The Bureau: XCOM Declassified
low 1024x768
59.6  fps      Compare
med. 1366x768
49.1  fps      Compare
high 1366x768
20.9  fps      Compare
ultra 1920x1080
11.2  fps      Compare
» With all tested laptops playable in detail settings med..
Splinter Cell: Blacklist
med. 1366x768
49.8  fps      Compare
high 1366x768
23.6  fps      Compare
» With all tested laptops playable in detail settings med..
Dota 2

Dota 2

2013
low 1024x768
99.1 119.7 ~ 109 fps      Compare
med. 1366x768
70.7 75 ~ 73 fps      Compare
